ATEN 2-Port USB DVI Dual-View KVM Switch with Audio & USB 2.0 Hub (KVM cables included)
ATEN 2-Port USB DVI Dual-View KVM Switch with Audio & USB 2.0 Hub (KVM cables included), 2560 x 1600 pixels, Ethernet LAN, Rack mounting, 10.6 W, 1U, Black, Silver
Availability:: Arriving soon
The CS1642A 2-Port USB DVI Dual View KVMP™ Switch is a multi-application device that integrates a 2-port KVM switch with 2-port USB hub. The newest version now supports Quad-View functionality with two Dual View KVM Switches connected.1 x CS1642A 2-Port USB DVI Dual View KVMP™ Switch4 x (2 x 2L-7D02UD- 2 x LIN5-26W1-W11G) Custom DVI-D Dual Link Cable Sets (1.8m)1 x 0AD8-1605-24M1 Power Adapter1 x User Instructions
| Ports & interfaces | |
|---|---|
| Number of computers controlled | 2 |
| Keyboard port type | USB |
| Mouse port type | USB |
| Video port type | DVI-I |
| DVI-I ports quantity | 6 |
| Console ports | 3.5mm headphone,3.5mm mic,DVI-I,USB A |
| Console USB ports quantity | 2 |
| USB 2.0 Type-A hub ports quantity | 2 |
| Audio connections | Y |
| Headphone outputs | 2 |
| Number of microphone inputs | 1 |
| DC-in jack | Y |
| Network | |
| Ethernet LAN | Y |
| Ethernet LAN (RJ-45) ports | 1 |
| Performance | |
| Maximum resolution | 2560 x 1600 |
| Video bandwidth | 60 |
| Scan interval | 1,99 |
| Design | |
| Rack mounting | Y |
| Rack capacity | 1U |
| Product colour | Black,Silver |
| Housing material | Metal,Plastic |
| LED indicators | Y |
| Push button | Y |
| Hot keys | Y |
| Display | |
| Built-in display | N |
| Power | |
| Power source | DC |
| Input voltage | 5.3 |
| Power consumption (typical) | 10.6 |
| System requirements | |
| Windows operating systems supported | Y |
| Linux operating systems supported | Y |
| Mac operating systems supported | Y |
| Other operating systems supported | Y |
| Sustainability | |
| Compliance certificates | RoHS |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 50 |
| Storage temperature (T-T) | -20 - 60 |
| Operating relative humidity (H-H) | 0 - 80 |
| Weight & dimensions | |
| Width | 262.3 |
| Depth | 76.8 |
| Height | 44 |
| Weight | 1720 |
| Packaging data | |
| Package width | 98 |
| Package depth | 325 |
| Package height | 210 |
| Package weight | 2000 |
| Packaging content | |
| Cables included | DVI,KVM |
| Quick installation guide | Y |
| Manual | Y |
| AC adapter included | Y |
| Logistics data | |
| Master (outer) case net weight | 8600 |
| Harmonized System (HS) code | 85176200 |
| Master (outer) case width | 342 |
| Master (outer) case length | 512 |
| Master (outer) case height | 232 |
| Master (outer) case gross weight | 10940 |
| Products per master (outer) case | 5 |
