D-Link GO-SW-16G Unmanaged L2 Gigabit Ethernet (10/100/1000) 1U Black
(0 review)Add your review
€52,21

D-Link GO-SW-16G, Unmanaged, L2, Gigabit Ethernet (10/100/1000), Full duplex, Rack mounting, 1U

Availability: In Stock
EAN:790069396618Categories:NetworkingTags:

The GO-SW-16G/24G 16/24‑Port Gigabit Easy Desktop Switch is an economical, plug-and-play networking switch solution for SOHO and small and medium businesses wanting to benefit from the increased bandwidth of Gigabit Ethernet. It provides 16 or 24 10/100/1000 Mbps ports that enable you to easily expand your network and provide a quick way to upgrade your network to fast connectivity.The GO-SW-16G/24G 16/24‑Port Gigabit Easy Desktop Switch is an economical, plug-and-play networking switch solution for SOHO and small and medium businesses wanting to benefit from the increased bandwidth of Gigabit Ethernet. It provides 16 or 24 10/100/1000 Mbps ports that enable you to easily expand your network and provide a quick way to upgrade your network to fast connectivity.Upgrade to Gigabit NetworkingWith data transfer speeds of up to 2000 Mbps at full-duplex, this switch is ideal for quick file transfers, online gaming, and smooth streaming media. It features easy-to-access Ethernet ports with LED indicators per port to easily distinguish link status. Auto-MDI/MDIX crossover makes connections a cinch; just plug in your cables and you are ready to go.Conserve EnergyThe GO-SW-16G/24G supports IEEE 802.3az Energy-Efficient Ethernet, which saves energy and reduces heat automatically without sacrificing performance or functionality. The switch can detect when a connected computer is shut down or when there is no Ethernet traffic and can automatically reduce the power used for that port, cutting power usage substantially. In addition, the switch optimises power usage for each port based on the length of cable connected to it, using only as much power as is required. Both of these features work together to help you save power automatically.Reliable Plug and Play InstallationThe GO-SW-16G/24G is a plug-and-play device that requires no configuration, so setup is simple and hassle-free, and you can easily connect multiple computers, share files, music, and video across your home or small office network, or even create a multiplayer gaming environment. IEEE 802.3x flow control on each port minimizes dropped packets when the port’s receiving buffer is full, giving you a more reliable connection for all of your connected devices.

Management features
Switch typeUnmanaged
Switch layerL2
Quality of Service (QoS) supportY
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity16
Basic switching RJ-45 Ethernet ports typeGigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity16
Power connectorDC-in jack
Network
Networking standardsIEEE 802.1p,IEEE 802.3,IEEE 802.3ab,IEEE 802.3az,IEEE 802.3u,IEEE 802.3x
10G supportN
Copper ethernet cabling technology1000BASE-T,100BASE-TX,10BASE-T
Full duplexY
Half duplexY
Flow control supportY
Auto MDI/MDI-XY
Ethernet LAN data rates10,100,1000 Mbit/s
Auto-negotiationY
Data transmission
Switching capacity32 Gbit/s
Forwarding rate23.81 Mpps
MAC address table8000 entries
Store-and-forwardY
Number of queues8
Jumbo frames supportY
Jumbo frames9216
Packet buffer memory0.512 MB
Design
Rack mountingY
Form factor1U
Product colourBlack
Housing materialMetal
LED indicatorsY
Number of fans0 fan(s)
Performance
Mean time between failures (MTBF)305171 h
Power
Power supply includedY
Redundant power supply (RPS) supportN
Number of power supply units1
DC input voltage12 V
Input current1 A
Power consumption (max)11.7 W
Power over Ethernet (PoE)
Power over Ethernet (PoE)N
Operational conditions
Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-40 - 70 °C
Operating relative humidity (H-H)10 - 90 %
Storage relative humidity (H-H)5 - 95 %
Heat dissipation39.92 BTU/h
Weight & dimensions
Width280 mm
Depth126 mm
Height44 mm
Weight870 g
Packaging data
Package width180 mm
Package depth328 mm
Package height108 mm
Package weight1450 g
Technical details
Shipping (inner) case height384 mm
Shipping (inner) case width340 mm
Shipping (inner) case length569 mm
Shipping (inner) case net weight15000 g
Products per shipping (inner) case10 pc(s)
Pallet gross weight (air)491500 g
Master (outer) cases per pallet (air)30 pc(s)
Products per pallet (air)300 pc(s)
Pallet gross length1100 mm
Pallet gross width1200 mm
Pallet height (air)2055 mm
Pallet gross weight (sea)491500 g
Master (outer) cases per pallet (sea)30 pc(s)
Products per pallet (sea)300 pc(s)
Pallet height (sea)2055 mm
Shipping (inner) case gross weight15550 g
Certificates
CertificationCE Class A, FCC Class A, VCCI Class A, BSMI, CCC UL, CB, LVD, BSMI, CCC
Logistics data
Harmonized System (HS) code85176990
