ATEN 32-Port 9-Bus KVM Over IP Switch, with Audio & Virtual Media Support

€8841,38

ATEN 32-Port 9-Bus KVM Over IP Switch, with Audio & Virtual Media Support, 1920 x 1200 pixels, Ethernet LAN, WUXGA, Black

Availability:: Arriving soon

Add to Cart

Add to wishlist

Compare

EAN:4719264643019Categories:Networking

ATEN's 4th generation of KVM over IP switches exceed expectations. The KN8132V features superior video quality (Full HD resolution of 1920 x 1200), FIPS 140-2 with level 1 security standards and virtual media transmissions at twice the speed. The KN series provides local console and remote over IP access for users to monitor and access their entire data center over a network. In addition, it offers out-of-band access with external modem support for BIOS-level troubleshooting when the network is down.1x KN8132V KVM over IP Switch2x SA0142 Serial Adapters (RJ45-F to DB9-M; DTE to DCE)2x LIN2-418K-E12G Power Cords1x Mounting Kit2x 0X12-0017-301G Lok-U-Plugs1x 0X12-0017-401G Lok-U-Plug Installation Tool1x Foot Pad Set (4 pcs.)1x User Instructions

Ports & interfaces
Number of computers controlled	32
Keyboard port type	USB, PS/2
Mouse port type	USB, PS/2
Video port type	DVI-D/VGA
DVI-D ports quantity	1
VGA (D-Sub) ports quantity	1
Console ports	DVI-D,RJ–45,USB A,VGA (D-Sub)
Console USB ports quantity	2
USB 2.0 ports quantity	3
Audio connections	Y
DC-in jack	Y
Network
Ethernet LAN	Y
Ethernet LAN (RJ-45) ports	32
Cabling technology	10/100/1000Base-T(X)
Security algorithms	FIPS 140-2
Performance
HD type	WUXGA
Maximum resolution	1920 x 1200 pixels
Scan interval	1,255 s
Number of users	8 user(s)
Design
Product colour	Black
Housing material	Metal
LED indicators	Link,Power
Push button	Y
Display
Built-in display	N
Power
Input voltage	110-240 V
AC input frequency	50 - 60 Hz
Input current	1 A
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-20 - 60 °C
Operating relative humidity (H-H)	0 - 80 %
Weight & dimensions
Width	433.6 mm
Depth	412.1 mm
Height	44 mm
Weight	6360 g
Packaging data
Package width	521 mm
Package depth	570 mm
Package height	152 mm
Package weight	7800 g
Packaging content
Cables included	AC
Quick installation guide	Y
Rack mount kit	Y
Logistics data
Master (outer) case net weight	6360 g
Harmonized System (HS) code	85176200
Master (outer) case width	521 mm
Master (outer) case length	570 mm
Master (outer) case height	152 mm
Master (outer) case gross weight	7800 g
Products per master (outer) case	1 pc(s)
