TP-Link Omada 10-Port Gigabit Smart Switch with 8-Port PoE+

€149,88

TP-Link Omada 10-Port Gigabit Smart Switch with 8-Port PoE+, Managed, L2/L2+, Gigabit Ethernet (10/100/1000), Power over Ethernet (PoE), Rack mounting, 1U

Availability: In Stock

Add to Cart

Add to wishlist

Compare

EAN:6935364030674Categories:NetworkingTags:

TP-Link’s brand new Omada smart switches provide huge upgrade comparing with previous versions. The switches can be managed by Omada SDN Controller, which provides professional and reliable one-step solutions. Integrated L2 and L2+ features such as 802.1Q VLAN, QoS, IGMP Snooping and static routing provide cost-effective networking solutions for small and medium-sized businesses without sacrificing enhanced usability and strong performance.

Management features
Switch type	Managed
Switch layer	L2/L2+
Quality of Service (QoS) support	Y
Web-based management	Y
Cloud-managed	Y
ARP inspection	Y
Configuring Location Settings (CLI)	Y
System event log	Y
MIB support	RFC2925, RFC2618, RFC2620, RFC2021, RFC2819, RFC2674, RFC1213, RFC2233, RFC1643, RFC1493
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity	8
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity	8
SFP module slots quantity	2
Network
Networking standards	IEEE 802.1D,IEEE 802.1Q,IEEE 802.1p,IEEE 802.1s,IEEE 802.1w,IEEE 802.1x,IEEE 802.3ab,IEEE 802.3ad,IEEE 802.3af,IEEE 802.3at,IEEE 802.3az,IEEE 802.3i,IEEE 802.3u,IEEE 802.3x,IEEE 802.3z
10G support	N
Copper ethernet cabling technology	10BASE-T,100BASE-TX,1000BASE-T
Port mirroring	Y
Flow control support	Y
Link aggregation	Y
Broadcast storm control	Y
Rate limiting	Y
Spanning tree protocol	Y
VLAN support	Y
Virtual LAN features	MAC address-based VLAN,Multicast VLAN,Protocol-based VLAN,Tagged VLAN,Voice VLAN
Number of VLANs	4000
Optical fiber
Fiber ethernet cabling technology	100BASE-FX,1000BASE-X
Data transmission
Switching capacity	20 Gbit/s
Forwarding rate	14.9 Mpps
MAC address table	8000 entries
Number of queues	8
Jumbo frames support	Y
Jumbo frames	9000
Packet buffer memory	4.1 MB
Security
DHCP features	DHCP client,DHCP relay,DHCP server,DHCP snooping,DHCPv6 client,DHCPv6 snooping
Access Control List (ACL)	Y
IGMP snooping	Y
Security algorithms	EAP-LEAP,EAP-MD5,EAP-TLS,EAP-TTLS,HTTPS,SNMP,SNMPv2,SNMPv3,SSH,SSH-2,SSL/TLS
SSH/SSL support	Y
BPDU filtering/protection	Y
IP-MAC-Port binding	Y
Queue scheduling algorithms	SP,Weighted Round Robin (WRR)
Multicast features
Multicast support	Y
Protocols
Management protocols	SNMPv1/v2c/v3, SNTP
Design
Rack mounting	Y
Form factor	1U
Product colour	Black
Number of fans	1 fan(s)
Power
Power source	AC
Power supply included	Y
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Power consumption (max)	173.9 W
Power over Ethernet (PoE)
Power over Ethernet (PoE)	Y
Power over Ethernet plus (PoE+) ports quantity	8
Total Power over Ethernet (PoE) budget	150 W
Operational conditions
Operating temperature (T-T)	0 - 50 °C
Storage temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	10 - 90 %
Storage relative humidity (H-H)	5 - 90 %
Heat dissipation	594.46 BTU/h
Weight & dimensions
Width	294 mm
Depth	180 mm
Height	44 mm
Certificates
Certification	CE, FCC, RoHS
