CyberPower OL1500ERTXL2U uninterruptible power supply (UPS) Double-conversion (Online) 1.5 kVA 1350 W 8 AC outlet(s)
CyberPower OL1500ERTXL2U, Double-conversion (Online), 1.5 kVA, 1350 W, Pure sine, 190 V, 300 V
Availability: In Stock
The Online Series UPS is ideal for servers, networking equipment, workstations and other mission-critical applications which require Pure Sineware power protection. Featuring Online Double Conversion design and Zero Transfer Time, it can provide consistent and seamless Pure Sinewave power to critical loads. With the add-on advantage of Extended Runtime (XL) battery packs, the UPS backup time can be extended to maximize workflow flexibility. An optional SNMP/HTTP Remote Management Capability enables remote management and control of the system through standard web browser. The included PowerPanel® Business Edition management software provides corporate servers and critical workstations comprehensive network power management including unattended-shutdown, event logging, reporting, and notifications.
| Features | |
|---|---|
| UPS topology | Double-conversion (Online) |
| Output power capacity | 1.5 kVA |
| Output power | 1350 W |
| Waveform | Pure sine |
| Input operation voltage (min) | 190 V |
| Input operation voltage (max) | 300 V |
| Input frequency | 40/70 Hz |
| Output operation voltage (min) | 200 V |
| Output operation voltage (max) | 240 V |
| Output frequency | 50/60 Hz |
| Maximum current | 7.5 A |
| Surge energy rating | 1780 J |
| Response time | 0 ms |
| Heat dissipation | 512 BTU/h |
| Output power factor | 0.9 |
| Emergency Power Off (EPO) | Y |
| Total Harmonic Distortion (THD) (linear load) | 3 % |
| Total Harmonic Distortion (THD) (non-linear load) | 5 % |
| EMI/RFI noise filtering | Y |
| Surge protection | Y |
| Surge protection features | Fax,Modem,Network,Telephone |
| Power protection features | Overload,Short circuit |
| Audible alarm(s) | Y |
| Audible alarm modes | Battery replacement |
| Ports & interfaces | |
| AC outlet types | C13 coupler |
| Power plug | C14 coupler |
| AC outlets quantity | 8 AC outlet(s) |
| USB 2.0 ports quantity | 1 |
| Serial interface | Y |
| Serial interface type | RS-232 |
| Serial ports quantity | 1 |
| RS-232 ports | 1 |
| Ethernet LAN (RJ-45) ports | 2 |
| Emergency Power Off (EPO) connector | Y |
| Battery | |
| Battery technology | Sealed Lead Acid (VRLA) |
| Typical backup time at full load | 3 min |
| Typical backup time at half load | 11 min |
| Battery recharge time | 5 h |
| Hot-swap battery | Y |
| Cold start | Y |
| Design | |
| Form factor | Rackmount/Tower |
| Housing material | Metal |
| Rack capacity | 2U |
| Cooling type | Active |
| Built-in fan | Y |
| Product colour | Black |
| Control type | Buttons |
| Display type | LCD |
| LED indicators | Y |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 45 °C |
| Operating relative humidity (H-H) | 0 - 90 % |
| Storage relative humidity (H-H) | 0 - 95 % |
| Operating altitude | 0 - 3000 m |
| Non-operating altitude | 0 - 15000 m |
| Certificates | |
| Compliance certificates | C-TICK,CE,RCM,RoHS |
| Packaging content | |
| Rack mount kit | Y |
| Cables included | Serial,USB cable |
| Manual | Y |
| Sustainability | |
| Sustainability compliance | Y |
| Weight & dimensions | |
| Width | 433 mm |
| Depth | 430 mm |
| Height | 88 mm |
| Weight | 18000 g |
| Packaging data | |
| Bundled software | PowerPanel® Business Edition |
| Package width | 575 mm |
| Package depth | 550 mm |
| Package height | 240 mm |
| Package weight | 24500 g |
| Logistics data | |
| Harmonized System (HS) code | 8504408590 |
| Warranty period | 3 year(s) |
| Country of origin | China |
| Other features | |
| Battery type | RBP0074 |
| Compatible operating systems | Windows 7 / Vista / XP / 2000, Server 2008 / 2003, Linux |
| Overload protection | Y |
