TP-Link 16-Port Gigabit Rackmount Network Switch
(0 review)Add your review
€60,32

TP-Link 16-Port Gigabit Rackmount Network Switch, Unmanaged, Gigabit Ethernet (10/100/1000), Full duplex, Rack mounting, 1U

Availability: In Stock
EAN:6935364020095Categories:NetworkingTags:

The TL-SG1016 Gigabit Ethernet Switch provides you with a high-performance, low-cost, easy-to-use, seamless and standard upgrade to improve old network to 1000Mbps network. All 16 ports support auto MDI/MDIX, no need to worry about the cable type, simply plug and play. Moreover, with the innovative energy-efficient technology, the TL-SG1016 can save power consumption and 80% of the packaging material can be recycled, making it an eco-friendly solution for your business network.TP-Link Green TechnologyThis new generation TL-SG1016 Gigabit Switch features the latest innovative energy-efficient technologies that can greatly expand your network capacity with much less power. It automatically adjusts power consumption according to the link status to limit the carbon footprint of your network. It also complies with the EU’S RoHS, prohibiting the use of certain hazardous materials. Besides, 80% of the packaging material can be recycled.High PerformanceAll 16 ports are Gigabit RJ-45 ports which can provide large file transferring and also be compatible with 10Mbps and 100Mbps Ethernet devices. Featuring non-blocking switching architecture, TL-SG1016 forwards and filters packets at full wire-speed for maximum throughput. With 10KB Jumbo frame, the performance of large files transfers is improved significantly. And IEEE 802.3x flow control for Full Duplex mode and backpressure for Half Duplex mode alleviate the tra­ffic congestion and make The TL-SG1016 work reliably. It’s a perfect choice to update your network to Gigabit while protecting your previous investment properly.Easy to UseThe auto features of this gigabit switch make installation plug and play and hassle-free. No configuring is required. Auto MDI/MDIX eliminates the need for crossover cables. Auto-negotiation on each port senses the link speed of a network device (10, 100, or 1000 Mbps) and intelligently adjusts for compatibility and optimal performance.

Management features
Switch typeUnmanaged
Quality of Service (QoS) supportY
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity16
Basic switching RJ-45 Ethernet ports typeGigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity16
Power connectorAC-in jack
Network
Networking standardsIEEE 802.3ab,IEEE 802.3i,IEEE 802.3u,IEEE 802.3x
10G supportN
Copper ethernet cabling technology10BASE-T,100BASE-TX,1000BASE-T
Cable types supportedCat3,Cat4,Cat5,Cat5e
Full duplexY
Half duplexY
Flow control supportY
Auto MDI/MDI-XY
Auto-negotiationY
Data transmission
Switching capacity32 Gbit/s
Forwarding rate23.8 Mpps
MAC address table8000 entries
Store-and-forwardY
Jumbo frames supportY
Jumbo frames10000
Design
Rack mountingY
Form factor1U
Product colourBlack
Housing materialMetal
LED indicatorsY
Performance
Compatible operating systemsMicrosoft Windows 2000/XP/2003/Vista/2008/7/2012/8/10 MacOS NetWare UNIX Linux
Maximum cable length100 m
FanlessY
Power
Power sourceAC
Power supply includedY
AC input voltage100 - 240 V
AC input frequency50/60 Hz
Power consumption (max)10.44 W
Power over Ethernet (PoE)
Power over Ethernet (PoE)N
Operational conditions
Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-40 - 70 °C
Operating relative humidity (H-H)10 - 90 %
Storage relative humidity (H-H)5 - 90 %
Heat dissipation35.6 BTU/h
Weight & dimensions
Width440 mm
Depth180 mm
Height44 mm
Packaging content
Cables includedAC
User guideY
Rack mount kitY
Packaging data
Package typeBox
Package width250 mm
Package depth528 mm
Package height80 mm
Package weight2040 g
Sustainability
Sustainability complianceY
Certificates
Compliance certificatesCE,Federal Communications Commission (FCC),RoHS
Logistics data
Harmonized System (HS) code85176990
