TP-Link Omada 48-Port Gigabit L2+ Managed Switch with 4 SFP Slots

€327,02

TP-Link Omada 48-Port Gigabit L2+ Managed Switch with 4 SFP Slots, Managed, L2+, Gigabit Ethernet (10/100/1000), Rack mounting, 1U

Availability: In Stock

Add to Cart

Add to wishlist

Compare

EAN:6935364010751Categories:NetworkingTags:

TP-Link | Omada L2+ managed switches provide high performance, powerful L2 and L2+ features like static routing, enterprise-level QoS, advanced security strategies and a bundle of ISP features. The IP-MAC-Port Binding (IMPB) and Access Control List (ACL) functions protect against broadcast storm, ARP and Denial-ofService (DoS) attacks, etc. Quality of Service (QoS, L2 to L4) provides enhanced traffic management capabilities to move your data smoother and faster. The OAM and DDM functions help facilitate network management. Moreover, the easy-to-use web management interfaces, along with CLI, SNMP and Dual Image mean faster setup and configuration with less downtime. TP-Link | Omada L2+ managed Switches provide a reliable, secure solution for enterprise, campus and ISP networks.

Management features
Switch type	Managed
Switch layer	L2+
Quality of Service (QoS) support	Y
Web-based management	Y
Cloud-managed	Y
ARP inspection	Y
Configuring Location Settings (CLI)	Y
System event log	Y
MIB support	Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity	48
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity	48
SFP module slots quantity	4
Console port	RJ-45/Micro-USB
Network
Networking standards	IEEE 802.1D,IEEE 802.1p,IEEE 802.1s,IEEE 802.1w,IEEE 802.3ab,IEEE 802.3i,IEEE 802.3u,IEEE 802.3z
10G support	N
Port mirroring	Y
IP routing	Y
Policy-based routing	Y
Flow control support	Y
Link aggregation	Y
Broadcast storm control	Y
Spanning tree protocol	Y
Head-of-line (HOL) blocking	Y
Ethernet LAN data rates	10,100,1000 Mbit/s
IPv4 routes	48
IPv6 routes	48
VLAN support	Y
Virtual LAN features	Port-based VLAN,Private VLAN,Protocol-based VLAN,Tagged VLAN,Voice VLAN
Number of VLANs	4000
Data transmission
Switching capacity	104 Gbit/s
Forwarding rate	77.38 Mpps
MAC address table	16000 entries
Store-and-forward	Y
Static route	Y
Jumbo frames support	Y
Jumbo frames	9000
Security
DHCP features	DHCP client,DHCP relay,DHCP server,DHCP snooping,DHCPv6 snooping
Access Control List (ACL)	Y
IGMP snooping	Y
MAC address filtering	Y
SSH/SSL support	Y
Loop protection	Y
BPDU filtering/protection	Y
IP-MAC-Port binding	Y
Authentication	MAC-based authentication,Port-based authentication
Authentication type	AAA,RADIUS,TACACS+
Multicast features
Multicast support	Y
Multicast Listener Discovery (MLD) snooping	Y
Protocols
Management protocols	SNMPv1/v2c/v3, SNTP
GARP VLAN Registration Protocol (GVRP)	Y
IPv4 & IPv6 features	IPv4/IPv6 access-control list (ACL),IPv6 Telnet,IPv6 ping,IPv6 tracert
Design
Rack mounting	Y
Form factor	1U
Product colour	Black
Performance
Internal memory	256 MB
Flash memory	32 MB
Fanless	Y
Power
Power source	AC
Power supply included	Y
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Power consumption (max)	34.86 W
Power over Ethernet (PoE)
Power over Ethernet (PoE)	N
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	10 - 90 %
Storage relative humidity (H-H)	5 - 90 %
Heat dissipation	118.94 BTU/h
Weight & dimensions
Width	440 mm
Depth	220 mm
Height	44 mm
Packaging content
Cables included	AC
Quick start guide	Y
Rack mount kit	Y
Certificates
Certification	CE, FCC, RoHS
