CLUB3D 1 to 8 HDMI™ Splitter Full 3D and 4K60Hz(600MHz)
CLUB3D 1 to 8 HDMI™ Splitter Full 3D and 4K60Hz(600MHz), HDMI, 8x HDMI, 3840 x 2160 pixels, Black, 4K Ultra HD, 60 Hz
Availability:: Arriving soon
The Club 3D CSV-1383 is a high-performance and small-sized 1 to 8 HDMI™ Ultra High Definition Splitter with hot plug and iron casing. It distributes the input of the HDMI™ signal into eight identical outputs at the same time. It provides high performance audio and video output through HDMI™ cables up to 4K@60Hz resolution and is capable of receiving and transmitting up to 6Gbps/600MHz bandwidth.This is a high-performance and small-sized HDMI™ splitter in a metal housing with an external Power Supply of 100-240VAC / 5V-3A DC, Power consumption(Max.) 11.3 Watt. It's an ideal assistant both at home and at work.Features:• Easy to Use: Install in seconds, no need for settings• One HDMI™ Input, eight HDMI™ outputs • Support 12-bit Deep Full HD, Full 3D, HDR and 4K60Hz video• Vertical Frequency Range 24-30-50-60Hz• Resolution HDTV Interlaced (50&60Hz) 480i,576i,1080i Progressive (50&60Hz) Max. up to 4K@60Hz• Support compressed audio• Support HDCP 2.2 • Power Protection: the power will get disconnected automatically once the voltage of the connected power adapter is above 5.5V (Note: the power protection circuit will be damaged if the voltage if above 30V, so avoid connecting power adapter with voltage above 30V)• OS Support: Windows10/11
| Ports & interfaces | |
|---|---|
| Video port type | HDMI |
| Video out | 8x HDMI |
| Video ports quantity | 9 |
| DC-in jack | Y |
| Features | |
| Product colour | Black |
| Maximum resolution | 3840 x 2160 pixels |
| HD type | 4K Ultra HD |
| 3D | Y |
| Maximum refresh rate | 60 Hz |
| HDCP version | 2.2 |
| Rack mounting | N |
| HDCP | Y |
| Easy to install | Y |
| Plug and Play | Y |
| LED indicators | Power,Status |
| Number of displays supported | 8 |
| Windows operating systems supported | Windows 10,Windows 11 |
| Network | |
| Ethernet LAN | N |
| Wi-Fi | N |
| Bluetooth | N |
| Weight & dimensions | |
| Width | 258 mm |
| Depth | 113 mm |
| Height | 35 mm |
| Weight | 770 g |
| Packaging data | |
| Quantity per pack | 1 pc(s) |
| Package width | 350 mm |
| Package depth | 130 mm |
| Package height | 55 mm |
| Package type | Box |
| Plastic packaging weight | 0 g |
| Paper/cardboard packaging weight | 137 g |
| Total plastic packaging weight | 0 g |
| Total paper/cardboard packaging weight | 0 g |
| Packaging content | |
| Manual | Y |
| AC adapter included | Y |
| Logistics data | |
| Harmonized System (HS) code | 8473 3020 |
