CyberPower OL6KERTHDL uninterruptible power supply (UPS) Double-conversion (Online) 6 kVA 6000 W 10 AC outlet(s)
CyberPower OL6KERTHDL, Double-conversion (Online), 6 kVA, 6000 W, Pure sine, 200 V, 240 V
Availability: In Stock
CyberPower OL6KERTHDL guarantees power backup protection for IT equipment, servers, workstations, NAS/Storage devices, telecom devices, networking devices, security/emergency systems, and surveillance systems. The UPS adopts double-conversion topology to provide high-quality power output in a compact design. This generator-compatible UPS features hot-swappable battery packs for maintenance without power interruption, and comes with additional ECO Mode to conserve power and save on energy costs.The UPS can employ Extended Battery Modules (EBM) to prolong runtimes, and adopts patented Battery Management Technology to balance battery string voltage for optimal battery lifespan. This model also features tiltable color LCD panel that allows users to monitor key power and battery information at a glance. The PowerPanel Power Management Software allows user to perform real-time monitoring and remote management of the UPS.
| Features | |
|---|---|
| UPS topology | Double-conversion (Online) |
| Output power capacity | 6 kVA |
| Output power | 6000 W |
| Waveform | Pure sine |
| Input operation voltage (min) | 200 V |
| Input operation voltage (max) | 240 V |
| Input frequency | 50/60 Hz |
| Output operation voltage (min) | 200 V |
| Output operation voltage (max) | 240 V |
| Output frequency | 50/60 Hz |
| Output frequency regulation | 10 Hz |
| Output voltage regulation | 2 % |
| Maximum current | 32 A |
| Surge energy rating | 2430 J |
| Response time | 0 ms |
| Heat dissipation | 1613 BTU/h |
| Number of input phases | 1 |
| Number of output phases | 1 |
| Efficiency (ECO mode) | 97 % |
| Input power factor | 0.99 |
| Output power factor | 1 |
| Power Factor Correction (PFC) type | Active |
| Crest factor | 3:1 |
| ECO mode | Y |
| Emergency Power Off (EPO) | Y |
| Total Harmonic Distortion (THD) (linear load) | 3 % |
| Total Harmonic Distortion (THD) (non-linear load) | 5 % |
| EMI/RFI noise filtering | Y |
| Noise level | 66 dB |
| Surge protection | Y |
| Power protection features | Overload |
| Audible alarm(s) | Y |
| Audible alarm modes | Alarm when on battery,Battery replacement,Fault,Low battery alarm,Overload alarm |
| Ports & interfaces | |
| AC outlet types | C13 coupler,C19 coupler,Terminal |
| Power plug | Terminal |
| AC outlets quantity | 10 AC outlet(s) |
| USB port | Y |
| USB 2.0 ports quantity | 1 |
| Serial interface | Y |
| Serial interface type | RS-232 |
| Serial ports quantity | 1 |
| RS-232 ports | 1 |
| Emergency Power Off (EPO) connector | Y |
| Battery | |
| Battery technology | Sealed Lead Acid (VRLA) |
| Battery voltage | 144 V |
| Number of batteries supported | 1 |
| Typical backup time at full load | 3.1 min |
| Typical backup time at half load | 10.4 min |
| Battery recharge time | 4 h |
| Hot-swap battery | Y |
| Design | |
| Form factor | Rackmount/Tower |
| Housing material | Metal |
| Product colour | Black |
| Control type | Buttons |
| Display type | LCD |
| LED indicators | Y |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -5 - 45 °C |
| Operating relative humidity (H-H) | 0 - 90 % |
| Storage relative humidity (H-H) | 0 - 95 % |
| Operating altitude | 0 - 3000 m |
| Non-operating altitude | 0 - 4500 m |
| Certificates | |
| Compliance certificates | CE,EAC,RCM,RoHS |
| Packaging content | |
| Cables included | Serial,USB cable |
| Manual | Y |
| Sustainability | |
| Sustainability compliance | Y |
| Sustainability certificates | ENERGY STAR |
| Weight & dimensions | |
| Width | 433 mm |
| Depth | 720 mm |
| Height | 130 mm |
| Weight | 53300 g |
| Packaging data | |
| Package width | 600 mm |
| Package depth | 1100 mm |
| Package height | 295 mm |
| Package weight | 65000 g |
| Logistics data | |
| Country of origin | China |
| Other features | |
| Battery type | RBP0174 |
