iiyama TW1025LASC-B1PNR computer monitor 25.6 cm (10.1") 1280 x 800 pixels LED Touchscreen
iiyama TW1025LASC-B1PNR, 25.6 cm (10.1"), 1280 x 800 pixels, LED, 25 ms
Availability:: Arriving soon
The ProLite TW1025LASC-B1PNR touch panel PC is a perfect choice for high-use environments such as booking rooms, information desks or other corporate and hospitality applications. The Optical Bonded Projective Capacitive (PCAP) 10-point touch technology ensures a seamless and accurate touch response and a lower light reflection, in addition, the display is protected against humidity and potential moisture development. Thanks to the pre-installed Android 12 operating system, it is possible to easily customize the monitor by installing applications directly to it. The Power over Ethernet technology (POE) allows to provide both data connection and power by a single cable, simplifying all installations. Thanks to the NFC/RFID reader, the touch panel PC allows to communicate wirelessly with enabled devices or tags within close proximity and the RGB Led bar will clearly and intuitively indicate the availability status of the room. Together with the built-in 5 megapixel camera, microphone and speakers it offers limitless, interactive installation possibilities.
| Display | |
|---|---|
| Display diagonal | 10.1 " |
| Display resolution | 1280 x 800 pixels |
| Native aspect ratio | 16:10 |
| Display technology | LED |
| Panel type | IPS |
| Touchscreen | Y |
| Touchscreen technology | Projected capacitive system |
| Number of simultaneous touchpoints | 10 |
| Display brightness (typical) | 450 cd/m² |
| Display brightness | 450 cd/m² |
| Response time | 25 ms |
| Response time measurement type | GTG (Gray to Gray) |
| Aspect ratio | 16:10 |
| Contrast ratio (typical) | 1000:1 |
| Viewing angle, horizontal | 160 ° |
| Viewing angle, vertical | 160 ° |
| Display number of colours | 16.7 million colours |
| Pixel pitch | 0.1692 x 0.1692 mm |
| Viewable size, horizontal | 218.4 mm |
| Viewable size, vertical | 137.2 mm |
| Display diagonal (metric) | 25.5 cm |
| Surface hardness | 6H |
| Colour depth | 8 bit |
| Performance | |
| Operating hours (hours/days) | 24/7 |
| Operating system installed | Android |
| Multimedia | |
| Number of speakers | 2 |
| RMS rated power | 4 W |
| Built-in speaker(s) | Y |
| Megapixel (approx.) | 5 MP |
| Built-in microphone | Y |
| Built-in camera | Y |
| Design | |
| Housing material | Plastic |
| Front bezel colour | Black |
| Glass thickness | 1.85 mm |
| Ports & interfaces | |
| USB 2.0 Type-A ports quantity | 1 |
| USB Touch port | Y |
| Card reader integrated | Y |
| Compatible memory cards | SD |
| Network | |
| Wi-Fi | Y |
| Wi-Fi standards | 802.11b,802.11g,Wi-Fi 4 (802.11n) |
| Bluetooth | Y |
| Bluetooth version | 5.2 |
| Ethernet LAN | Y |
| Ergonomics | |
| VESA mounting | Y |
| Panel mounting interface | 75 x 75 mm |
| Cable management | Y |
| Power | |
| Power consumption (typical) | 18 W |
| Power consumption (standby) | 0.5 W |
| Power consumption (off) | 0.3 W |
| AC adapter output voltage | 12 V |
| Power supply type | External |
| Weight & dimensions | |
| Width (with stand) | 259.5 mm |
| Depth (with stand) | 28 mm |
| Height (with stand) | 178.5 mm |
| Weight (with stand) | 1100 g |
| Packaging data | |
| Package width | 363 mm |
| Package depth | 363 mm |
| Package height | 225 mm |
| Packaging content | |
| Quick start guide | Y |
| Other features | |
| Built-in processor | Y |
| Weight | 1100 g |
| Height | 178.5 mm |
| Width | 259.5 mm |
| Depth | 28 mm |
| Near Field Communication (NFC) | Y |
| Ethernet LAN (RJ-45) ports | 1 |
| Certification | CE, EAC, RoHS support, ErP, WEEE, REACH, UKCA |
