ATEN 2-Port VGA Video Switch

€30,98

ATEN 2-Port VGA Video Switch, VGA, Metal, Plastic, Silver, 60 Hz, 10 m, 640 x 480 (VGA), 800 x 600 (SVGA), 1024 x 768 (XGA), 1600 x 1200 (UXGA), 1920 x 1440

Availability:: Arriving soon

Add to Cart

Add to wishlist

Compare

EAN:4710423771628Categories:AV Equipment

The VS291 is a video switch with 2 ports. It allows 2 independent computers to display their video outputs on a single monitor. Therefore, users will not need to buy monitors for each computer additionally.

Ports & interfaces
Video port type	VGA
VGA (D-Sub) ports quantity	3
VGA (D-Sub) input ports	2
VGA (D-Sub) output ports	1
DC-in jack	Y
Features
Material	Metal,Plastic
Product colour	Silver
Maximum refresh rate	60 Hz
Maximum operating distance	10 m
Supported graphics resolutions	640 x 480 (VGA),800 x 600 (SVGA),1024 x 768 (XGA),1600 x 1200 (UXGA),1920 x 1440
LED indicators	Y
Bandwidth	150 MHz
Maximum resolution	1920 x 1440 pixels
Input impedance	75 Ω
Output impedance	75 Ω
Power
Power consumption (typical)	0.82 W
Weight & dimensions
Width	65.2 mm
Depth	120 mm
Height	44 mm
Weight	220 g
Packaging data
Package width	59 mm
Package depth	239 mm
Package height	160 mm
Package weight	360 g
Packaging content
Quantity per pack	1 pc(s)
AC adapter included	Y
Operational conditions
Operating temperature (T-T)	0 - 50 °C
Storage temperature (T-T)	-20 - 60 °C
Operating relative humidity (H-H)	0 - 80 %
Storage relative humidity (H-H)	0 - 80 %
Logistics data
Harmonized System (HS) code	85176990
Master (outer) case width	315 mm
Master (outer) case length	490 mm
Master (outer) case height	338 mm
Master (outer) case gross weight	7900 g
Products per master (outer) case	20 pc(s)
Master (outer) case net weight	4400 g
