TP-Link DeltaStream 16-Port Pizza-Box GPON Optical Line Terminal

€4762,37

TP-Link DeltaStream 16-Port Pizza-Box GPON Optical Line Terminal, 1:128, 60000 m, Gigabit Ethernet, 100 - 240 V, 50 - 60 Hz, 38.4 - 72 V

Availability: In Stock

Add to Cart

Add to wishlist

Compare

EAN:4897098683620Categories:NetworkingTags:

DeltaStream 16-port Pizza-boxGPON Optical Line Terminal1:128 Split Ratio for High CapacitySupports 1:128 splitting ratio for every port—up to 2048 ONTs by one device.Redundant Dual Power SuppliesCarrier-class reliability with redundant dual power supplies supporting AC, DC or mixed power input.Compact Size for Flexible Deployment19 inch rack mount size is flexible and easy to deploy, suitable for different application scenarios.Centralized ManagementMakes maintenance easier with remote batch configuration and updates via DeltaStream PON Management System(DPMS), SNMP, CLI, and WEB UI.

Features
Static route	Y
DHCP server	Y
DHCP relay	Y
IGMP snooping	Y
Multicast Listener Discovery (MLD) snooping	Y
Quality of Service (QoS) support	Y
GPON split ratio (max)	1:128
Maximum operating distance (GPON)	60000 m
Access Control List (ACL)	Y
Ports & interfaces
Upstream ports	Gigabit Ethernet
Ethernet LAN (RJ-45) ports	4
GPON ports quantity	16
SFP/SFP+ slots quantity	4
Power
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
DC voltage range	38.4 - 72 V
Power consumption (max)	103 W
Operational conditions
Operating temperature (T-T)	0 - 50 °C
Storage temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	10 - 90 %
Storage relative humidity (H-H)	5 - 90 %
Weight & dimensions
Width	440 mm
Depth	440 mm
Height	44 mm
