ATEN 4-Port USB DVI Multi-View KVMP Switch
(0 review)Add your review
€1900,81

ATEN 4-Port USB DVI Multi-View KVMP Switch, 1920 x 1200 pixels, Ethernet LAN, Full HD, Rack mounting, 9.7 W, 1U

Availability: In Stock
EAN:4719264646867Categories:NetworkingTags:

ATEN CM1164A 4-Port USB DVI Multi-View KVMP™ Switch improves the operational efficiency of intensive monitoring applications. With limited screen, to allow users to manage the data more efficiently, up to 16 video sources can be selected, switched and displayed at the same time with independent keyboard, mouse control. The CM1164A provides users a real-time monitoring functionality by combining a 4-port DVI-D switch with a 2-port USB hub and providing the following display modes: Quad View, Picture in Picture (PiP), Picture by Picture (PbP), Picture on Picture (PoP), and Full Screen mode.1x CM1164A 4-Port USB DVI Multi-View KVMP™ Switch4x LIN5-35W1-W11G KVM Cables (DVI-D, USB, Audio)1x LIN2-418K-E12G Power Cord1x 2XRT-0013G IR Remote Control1x Rack Mount Kit1x User Instructions

Ports & interfaces
Number of computers controlled4
Keyboard port typeUSB
Mouse port typeUSB
Video port typeDVI-D
DVI-D ports quantity5
USB 2.0 Type-B ports quantity4
Console ports3.5mm headphone,DVI-D,RJ–45,USB A
Console USB ports quantity2
USB hubY
USB 2.0 Type-A hub ports quantity2
USB connector typeUSB Type-A,USB Type-B
Audio connectionsY
Headphone outputs6
Number of microphone inputs6
Network
Ethernet LANY
Ethernet LAN (RJ-45) ports2
Performance
HD typeFull HD
Maximum resolution1920 x 1200 pixels
Video bandwidth60 Hz
Scan interval5,10,15,30,60,90 s
HDCPY
Daisy chainY
Design
Rack mountingY
Rack capacity1U
Product colourBlack
Housing materialMetal
CascadableY
LED indicatorsY
Push buttonY
Hot keysY
Display
Built-in displayN
On Screen Display (OSD)Y
Power
Power sourceAC
Input voltage110 - 220 V
AC input frequency50 - 60 Hz
Power consumption (typical)9.7 W
Sustainability
Compliance certificatesRoHS
Operational conditions
Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-10 - 60 °C
Operating relative humidity (H-H)0 - 80 %
Weight & dimensions
Width437.2 mm
Depth164 mm
Height44 mm
Weight3980 g
Packaging data
Package width131 mm
Package depth540 mm
Package height233 mm
Package weight4435 g
Packaging content
Cables includedKVM
ManualY
AC adapter includedY
Rack mount kitY
Logistics data
Master (outer) case net weight11940 g
Harmonized System (HS) code85176200
Master (outer) case width420 mm
Master (outer) case length555 mm
Master (outer) case height255 mm
Master (outer) case gross weight14060 g
Products per master (outer) case3 pc(s)
