LevelOne PoE over Hybrid Cable Transmitter, 120W

€342,66

LevelOne PoE over Hybrid Cable Transmitter, 120W, Network transmitter, 2000 m, 100 Mbit/s, Full, 10/100Base-T(X), IEEE 802.3, IEEE 802.3u, IEEE 802.3x

Availability:: Arriving soon

Add to Cart

Add to wishlist

Compare

EAN:4015867187265Categories:Networking

Using hybrid fiber and copper cable, the LevelOne PFE range can deliver integrated power and data over a distance of 6,800 ft (2km) to a receiver which provides high-power PoE output for IP surveillance applications. A tough outdoor range (PFE-1011/1014) provides the same performance within a durable IP66-rated waterproof housing for harsh environmental conditions and temperature range of -40°C to 60°C.- Extend data and power up to 2km via a single Hybrid Fiber Cable- Enable PoE devices to distant remote location- Supporting high power consumption devices (up to 60W at 450m link)- Flexible installation option - 1 or 4 PoE output receivers selectable- Outdoor casing protects operation under wide temperature range (PFE-1011R/1014R)- Outdoor weatherproof models are sustainable from water and dust (PFE-1011R/1014R)

Performance
Type	Network transmitter
Maximum transfer distance	2000
Data transfer rate	100
Auto MDIX IEEE	Y
Auto-negotiation	Y
Duplex system	Full
Network
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.3,IEEE 802.3u,IEEE 802.3x
Ports & interfaces
Ethernet LAN (RJ-45) ports	1
Design
Product colour	Black
LED indicators	LAN,PoE,Power
Certification	CE, FCC
Power
AC input voltage	100-240
AC input frequency	50 - 60
Power consumption (typical)	120
External power adapter	Y
Power over Ethernet (PoE)	Y
Operational conditions
Operating temperature (T-T)	0 - 50
Storage temperature (T-T)	0 - 60
Operating relative humidity (H-H)	10 - 90
Storage relative humidity (H-H)	5 - 90
Weight & dimensions
Width	133
Depth	90
Height	28
Weight	250
Packaging content
Quick start guide	Y
AC adapter included	Y
Packaging data
Package width	222
Package depth	146
Package height	78
Package weight	200
Logistics data
Harmonized System (HS) code	85176990
