ATEN 8 Port True 4K HDMI Splitter
ATEN 8 Port True 4K HDMI Splitter, HDMI, 8x HDMI, 4096 x 2160 pixels, Black, Metal, 4K Ultra HD
Availability:: Arriving soon
The ATEN VS0108HB is designed for applications that require the routing of one HDMI source to 8 compatible display devices. It supports Dolby True HD and DTS HD Master Audio, video signals up to True 4K, data rates up to 18 Gbps, 3D, and HD lossless audio formats. Featuring ATEN EDID technology, the VS0108HB guarantees continuous EDID communication with connected devices and ensures that the HDMI sources power-up properly and maintain correct video outputs.1x VS0108HB 8-Port True 4K HDMI Splitter1x 0AD8-8005-40MG Power Adapter1x LIN2-418K-E12G Power Cord1x Mounting Kit1x User Instructions
| Ports & interfaces | |
|---|---|
| Video port type | HDMI |
| Video out | 8x HDMI |
| HDMI version | 2.0 |
| Video ports quantity | 9 |
| DC-in jack | Y |
| Features | |
| Product colour | Black |
| Housing material | Metal |
| Maximum resolution | 4096 x 2160 pixels |
| HD type | 4K Ultra HD |
| 3D | Y |
| Maximum operating distance | 3 m |
| Maximum refresh rate | 60 Hz |
| Bandwidth | 600 MHz |
| HDCP version | 2.2 |
| Rack mounting | Y |
| HDCP | Y |
| Plug and Play | Y |
| LED indicators | Y |
| Dolby technologies | DTS-HD Master Audio,Dolby TrueHD |
| Power | |
| Output voltage | 5 V |
| Power consumption (typical) | 11.95 W |
| Weight & dimensions | |
| Width | 157.8 mm |
| Depth | 437.2 mm |
| Height | 44 mm |
| Weight | 2580 g |
| Packaging data | |
| Package width | 131 mm |
| Package depth | 540 mm |
| Package height | 233 mm |
| Package weight | 3120 g |
| Packaging content | |
| Cables included | AC |
| AC adapter included | Y |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 80 % |
| Technical details | |
| Compliance certificates | RoHS |
| Logistics data | |
| Master (outer) case net weight | 7740 g |
| Harmonized System (HS) code | 85176990 |
| Master (outer) case width | 420 mm |
| Master (outer) case length | 565 mm |
| Master (outer) case height | 258 mm |
| Master (outer) case gross weight | 10600 g |
| Products per master (outer) case | 3 pc(s) |
