Vertiv SCMV285DPH-400 KVM switch Black
Vertiv SCMV285DPH-400, 3840 x 2160 pixels, 4K Ultra HD, Black
Availability:: Arriving soon
The Vertiv™ Cybex™ Secure MultiViewer KVM continues to provide the KVM solution required in accessing both classified and non-classified data. Through an all new, universal video port connector, the Cybex™ Secure MultiViewer supports a mixture of DP, HDMI, and DVI-D video connections without needing adapters. The Cybex™ Secure MultiViewer can be used in either a single or dual display scenario with up to 16 computers on a single screen and features such as tiling, windowing, and touch screen and features as tile, scale, picture-in-picture (PIP), or custom layout.- View information on a single display from multiple, isolated computers- Dual head display capabilities give the user visibility to computers across two displays in duplicate or extended screen mode- Provides flexible multiple screen layout options for users; Tile, Scale, PIP or custom- Block unauthorized USB devices while allowing secure switching of smart card and biometric devices between computers- Universal video connectors to support DP, HDMI, and DVI-D without adapters- Tamper-evident holographic labels to ensure hardware hasn’t been compromised- Enhances ability to multitask by keeping multiple critical systems in the user’s field of vision- Keyboard lock status indication on front of MultiViewer switch
| Ports & interfaces | |
|---|---|
| Keyboard port type | USB |
| Mouse port type | USB |
| Video port type | HDMI/DisplayPort |
| USB 2.0 Type-B ports quantity | 2 |
| Console ports | DisplayPort,HDMI,USB A |
| Console HDMI ports quantity | 2 |
| USB 2.0 Type-A hub ports quantity | 5 |
| Headphone outputs | 1 |
| Performance | |
| HD type | 4K Ultra HD |
| Maximum resolution | 3840 x 2160 |
| Video bandwidth | 30 |
| Design | |
| Product colour | Black |
| Certification | FCC Class A, CE, TUV US, TUV Canada, RCM, VCCI |
| Power | |
| Power source | AC |
| Input voltage | 100 - 240 |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 |
| Storage temperature (T-T) | -20 - 80 |
| Operating relative humidity (H-H) | 0 - 80 |
| Weight & dimensions | |
| Width | 442 |
| Depth | 183 |
| Height | 66 |
| Weight | 3700 |
