Conceptronic EMRICK 2-in-1 M.2 SSD PCIe Adapter SATA AHCI NVMe
Conceptronic EMRICK 2-in-1 M.2 SSD PCIe Adapter SATA AHCI NVMe, PCIe, M.2, PCIe 3.0, Passive, China, JMB585
Availability:: Arriving soon
This 2-in-1 M.2 SSD PCIe Adapter is a multi-functional NVMe conversion card, which can support the PCIe protocol NVMe SSD to connect directly to the motherboard, or the SATA Protocol NVMe SSD to connect to the motherboard SATA port with a SATA cable. It also features ultra-fast PCI Express 3.0 X4 lanes, transmitting bandwidth up to 32GT/S, as well as Serial ATA v3.0 to transmit at speeds up to 6Gbps. This adapter improves system speed, and will enhance the efficiency of office and entertainment equipment.
| Ports & interfaces | |
|---|---|
| Host interface | PCIe |
| Output interface | M.2 |
| Expansion card standard | PCIe 3.0 |
| SATA revision | 3.0 |
| Internal SATA ports quantity | 1 |
| Number of M.2 (M) slots | 1 |
| Number of M.2 (B) slots | 1 |
| Design | |
| Internal | Y |
| Cooling type | Passive |
| Country of origin | China |
| Features | |
| Chipset | JMB585 |
| Data transfer rate (max) | 6 |
| Plug and Play | Y |
| System requirements | |
| Windows operating systems supported | Windows 10,Windows 10 Education,Windows 10 Education x64,Windows 10 Enterprise,Windows 10 Enterprise x64,Windows 10 Home,Windows 10 Home x64,Windows 10 IOT Core,Windows 10 IoT Enterprise,Windows 10 Pro,Windows 10 Pro x64,Windows 10 x64,Windows 8,Windows 8 Enterprise,Windows 8 Enterprise x64,Windows 8 Pro,Windows 8 Pro x64,Windows 8 x64,Windows 8.1,Windows 8.1 Enterprise,Windows 8.1 Enterprise x64,Windows 8.1 Pro,Windows 8.1 Pro x64,Windows 8.1 x64 |
| Linux operating systems supported | Y |
| Weight & dimensions | |
| Width | 70 |
| Depth | 114 |
| Height | 18 |
| Weight | 42 |
| Packaging data | |
| Cables included | SATA |
| Mounting brackets included | Y |
| Screws included | Y |
| Quick installation guide | Y |
| Package width | 132 |
| Package depth | 156 |
| Package height | 26 |
| Package weight | 100 |
| Logistics data | |
| Harmonized System (HS) code | 84733020 |
| Products per master (outer) case | 30 |
| Master (outer) case width | 280 |
| Master (outer) case length | 180 |
| Master (outer) case height | 415 |
| Master (outer) case gross weight | 3600 |
