GIGABYTE Z890 AI TOP Motherboard - Supports Intel Core Ultra (Series 2) CPUs, 16+1+2 phases VRM, up to 9500MHz DDR5 (OC), 1xPCIe 5.0 + 3xPCIe 4.0 M.2, Wi-Fi 7, 10 GbE LAN, Thunderbolt 5
(0 review)Add your review
€704,03

GIGABYTE Z890 AI TOP Motherboard - Supports Intel Core Ultra (Series 2) CPUs, 16+1+2 phases VRM, up to 9500MHz DDR5 (OC), 1xPCIe 5.0 + 3xPCIe 4.0 M.2, Wi-Fi 7, 10 GbE LAN, Thunderbolt 5, Intel, LGA 1851 (Socket V1), Intel Core Ultra (Series 2), LGA 1851, DDR5-SDRAM, 256 GB

Availability:: Arriving soon
-
+
Add to Cart
Add to wishlist
Compare
Share
EAN:4719331866051Categories:Hardware Components

Elevate your computing experience with GIGABYTE's renowned motherboard series: AORUS, AERO, and GIGABYTE. Featuring innovative designs and advanced features, these boards offer exceptional performance and reliability. Whether you're a gamer, content creator, or professional, our series cater to your needs, ensuring uncompromising quality and cutting-edge

Processor
Processor manufacturerIntel
Processor socketLGA 1851 (Socket V1)
Compatible processor seriesIntel Core Ultra (Series 2)
Supported processor socketsLGA 1851
Memory
Supported memory typesDDR5-SDRAM
Number of memory slots4
Memory slots typeDIMM
Memory channelsDual-channel
ECC сompatibilitynon-ECC
Supported memory clock speeds5600,5800,6000,6200,6400,6600,6800,7000,7200,7400,7600,7800,7900,7950,8000,8200,8266,8400,8600,8800,8933,9066,9200,9333,9466,9500
Supported memory clock speed (max)9500
Maximum internal memory256
Unbuffered memoryY
Maximum internal memory per slot64
Storage controllers
Supported storage drive typesHDD & SSD
Supported storage drive interfacesM.2,SATA III
Number of HDDs supported8
Number of storage drives supported12
RAID supportY
RAID levels0,1,5,10
Graphics
Parallel processing technology supportNot supported
Maximum resolution7680 x 4320
HDCPY
DirectX version12.0
Internal I/O
USB 2.0 connectors2
USB 3.2 Gen 1 (3.1 Gen 1) connectors2
USB 3.2 Gen 2x2 connectors2
Number of SATA III connectors8
Front panel audio connectorY
Front panel connectorY
ATX Power connector (24-pin)Y
CPU fan connectorY
Number of CPU fan connectors2
Number of chassis fan connectors6
EPS power connector (8-pin)Y
Number of EPS power connectors (8-pin)2
TPM connectorY
Thunderbolt headers1
12V power connectorY
Number of water pump connectors3
Number of temperature sensor headers2
Number of noise detection headers1
RGB LED pin headerY
Number of RGB LED pin headers4
Rear panel I/O ports
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity2
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity6
Ethernet LAN (RJ-45) ports2
HDMI ports quantity1
HDMI version2.1
DisplayPorts quantity1
DisplayPort version2.1
Headphone outputs1
Line-inY
Thunderbolt ports quantity2
WiFi-AP antenna jack2
Network
Ethernet LANY
Ethernet interface type10 Gigabit Ethernet
LAN controllerMarvell AQtion AQC113C
Wi-FiY
Top Wi-Fi standardWi-Fi 7 (802.11be)
Wi-Fi standards802.11a,802.11b,802.11g,Wi-Fi 4 (802.11n),Wi-Fi 5 (802.11ac),Wi-Fi 6 (802.11ax),Wi-Fi 6E (802.11ax),Wi-Fi 7 (802.11be)
WLAN controller modelIntel Wi-Fi 7 BE200
BluetoothY
Bluetooth version5.4
Features
Motherboard chipsetIntel Z890
Audio chipESS ES9260
Audio output channels2.0
Product colourBlack
PC health monitoringFAN,Temperature,Voltage,Water cooling
Component forPC
Motherboard form factorExtended ATX
Motherboard chipset familyIntel
Power source typeATX
Windows operating systems supportedWindows 11 x64
Expansion slots
PCI Express x16 (Gen 4.x) slots1
PCI Express x16 (Gen 5.x) slots2
Number of M.2 (M) slots4
1st M.2 largest key size25110
1st M.2 highest PCI Express generation5.0
2nd M.2 largest key size25110
2nd M.2 highest PCI Express generation4.0
3rd M.2 largest key size22110
3rd M.2 highest PCI Express generation4.0
4th M.2 largest key size22110
4th M.2 highest PCI Express generation4.0
BIOS
BIOS typeUEFI AMI
BIOS memory size256
ACPI version5.0
Clear CMOS jumperY
Desktop Management Interface (DMI) version2.7
System Management BIOS (SMBIOS) version2.7
Logistics data
Country of originTaiwan
Products per shipping (inner) case1
Battery
Battery weight3
Lithium weight per battery0.07
Number of battery cells1
Battery technologyLithium-Manganese Dioxide (LiMnO2)
Battery typeCR2032
Packaging data
Package width400
Package depth335
Package height430
Package weight4100
Weight & dimensions
Width305
Depth285
Height35
Packaging content
Batteries includedY
Antenna includedY
Screws includedY
Bundled softwareNorton® Internet Security (OEM version) LAN bandwidth management software
Other features
Weight3530
Technical details
Warranty period3
