D-Link 12-Port L2 Managed Switch Switch with 8 x 10/100/1000BaseT(X) & 4 x 100/1000BaseSFP
(0 review)Add your review
€1003,86

D-Link 12-Port L2 Managed Switch Switch with 8 x 10/100/1000BaseT(X) & 4 x 100/1000BaseSFP, Managed, L2, Gigabit Ethernet (10/100/1000), Full duplex, Wall mountable

Availability: Arriving Soon
EAN:0790069437915Categories:NetworkingTags:

Managed CustomizationFeatures user management interfaces, including an industrial-like CLI, and WEB-based management, the DIS-300G-12SW is easy to manage and provides the security and controls to guard and shape your network needs.Gigabit Connectivity with SFP slotsDesigned with 8 x 100/1000BaseT ports and 4 x 100/1000Base SFP to suit a range of devices and network layouts.Officially CertifiedCertifications for vibration, shock, free-fall, and electromagnetic compatibility to maximise network uptime in a variety of deployment environments, including smart city surveillance, factory automation, and outdoor wireless networks.Withstands Extreme TemperaturesOperates effortlessly in a range of industrial and harsh environments in temperatures from -40°C to +75°C, and can cold start from -40°C.Strong BuildThe tough housing has been created to keep your network protected and reliably rugged. That’s why every DIS-switch comes with a 5-year D-Link warranty.High AvailabilityRapid ring failover recovery time of Fast DeploymentFor instant installation it features a snap-to-DIN-rail clip, and also supports wall mounting.Fanless DesignWith no moving parts inside to reduce downtime and maintenance call outs, the rugged housing has been optimised for the transfer of heat.Discrete SizeSmall but mighty. To make the most of cabinet space, it measures: 61 x 154 x 109 mm.

Management features
Switch typeManaged
Switch layerL2
Quality of Service (QoS) supportY
Web-based managementY
Traffic shapingY
System event logY
MIB supportRFC 1757 RMON 1,2,3,9; RFC 2674 Q MIB RFC‑1213 MIB‑II; RFC‑1493 MIB; RFC 2233 IF MIB
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity8
Basic switching RJ-45 Ethernet ports typeGigabit Ethernet (10/100/1000)
SFP module slots quantity4
Fiber optic connectorLC
Network
Networking standardsIEEE 802.1D,IEEE 802.1ab,IEEE 802.1ad,IEEE 802.1p,IEEE 802.1s,IEEE 802.1w,IEEE 802.3ad,IEEE 802.3x
10G supportN
Full duplexY
Flow control supportY
Link aggregationY
Broadcast storm controlY
Auto MDI/MDI-XY
Spanning tree protocolY
Auto-negotiationY
VLAN supportY
Virtual LAN featuresTagged VLAN,Protocol-based VLAN,Port-based VLAN
Number of VLANs1024
Data transmission
MAC address table8000
Store-and-forwardY
Jumbo frames supportY
Jumbo frames9000
Security
DHCP featuresDHCP server,DHCP snooping,DHCP relay,DHCP client
Security algorithmsHTTPS,SNMP,SNMPv3,SSH
Authentication typeIEEE 802.1x,RADIUS
Queue scheduling algorithmsWeighted Round Robin (WRR)
Multicast features
Multicast supportY
Design
Rack mountingN
Product colourBlack
LED indicatorsLAN,Status
International Protection (IP) codeIP30
Wall mountableY
DIN rail mountingY
Electromagnetic compatibilityFCC 15, EN 61000‑6‑2, EN 61000‑6‑4, EN 61000‑4‑2, ‑3, ‑4, ‑5, ‑6
Performance
Firmware upgradeableY
Power
DC input voltage12 - 58
Power consumption (max)17
Power protection featuresOver current,Reverse polarity
Power over Ethernet (PoE)
Power over Ethernet (PoE)N
Operational conditions
Operating temperature (T-T)-40 - 75
Storage temperature (T-T)-40 - 85
Operating relative humidity (H-H)5 - 95
Weight & dimensions
Width61
Depth154
Height109
Weight1086
Packaging data
Package width195
Package depth242
Package height118
Package weight1530
Technical details
Shipping (inner) case height270
Shipping (inner) case width410
Shipping (inner) case length600
Shipping (inner) case net weight15300
Products per shipping (inner) case10
Pallet gross weight (air)346700
Master (outer) cases per pallet (air)20
Products per pallet (air)200
Pallet gross length1200
Pallet gross width1100
Pallet height (air)1485
Pallet gross weight (sea)478580
Master (outer) cases per pallet (sea)28
Products per pallet (sea)280
Pallet height (sea)2025
Shipping (inner) case gross weight16485
Certificates
CertificationIEC60068‑2‑6, IEC60068‑2‑27, IEC60068‑2‑32, UL 60950‑1, CE, FCC, RoHS, WEEE
Logistics data
Harmonized System (HS) code85176990
