ATEN 32-Port Cat 5e/6 KVM Switch
ATEN 32-Port Cat 5e/6 KVM Switch, 1920 x 1200 pixels, Ethernet LAN, Full HD, Rack mounting, 4.8 W, 1U
Availability: Arriving Soon
The KH1532A KVM switches are control units that allow IT administrators to access and control multiple computers from a single PS/2 or USB KVM console (keyboard, monitor, and mouse). Operators can take control of up to 32 (KH1532A) computers. By daisy chaining up to 31 additional switches, as many as 1024 computers can be controlled from a central KVM console.1x KH1532A Cat 5 High-Density KVM Switch1x LIN5-04A2-J11G Firmware Upgrade Cable1x LIN2-418K-E12G Power Cord1x Rack Mount Kit1x Foot Pad Set (4 pcs.)1x User Instructions
| Ports & interfaces | |
|---|---|
| Number of computers controlled | 32 |
| Keyboard port type | USB, PS/2 |
| Mouse port type | USB, PS/2 |
| Video port type | VGA |
| VGA (D-Sub) ports quantity | 1 |
| Console ports | PS/2,USB A,VGA (D-Sub) |
| Console USB ports quantity | 2 |
| USB connector type | USB Type-A |
| PS/2 ports quantity | 2 |
| Network | |
| Ethernet LAN | Y |
| Ethernet LAN (RJ-45) ports | 32 |
| Performance | |
| HD type | Full HD |
| Maximum resolution | 1920 x 1200 pixels |
| Scan interval | 1,255 s |
| Daisy chain | Y |
| Number of users | 10 user(s) |
| Firmware upgradeable | Y |
| Design | |
| Rack mounting | Y |
| Rack capacity | 1U |
| Product colour | Black |
| Housing material | Metal |
| LED indicators | Y |
| Push button | Y |
| Hot keys | Y |
| Display | |
| Built-in display | N |
| On Screen Display (OSD) | Y |
| Power | |
| Power source | AC |
| Input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Input current | 1 A |
| Power consumption (typical) | 4.8 W |
| Sustainability | |
| Compliance certificates | RoHS |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 80 % |
| Weight & dimensions | |
| Width | 437.2 mm |
| Depth | 163.7 mm |
| Height | 44 mm |
| Weight | 3260 g |
| Packaging data | |
| Package width | 131 mm |
| Package depth | 540 mm |
| Package height | 233 mm |
| Package weight | 3750 g |
| Packaging content | |
| Cables included | AC |
| Manual | Y |
| Rack mount kit | Y |
| Logistics data | |
| Master (outer) case net weight | 9780 g |
| Harmonized System (HS) code | 85176200 |
| Master (outer) case width | 420 mm |
| Master (outer) case length | 565 mm |
| Master (outer) case height | 258 mm |
| Master (outer) case gross weight | 11900 g |
| Products per master (outer) case | 3 pc(s) |
