ATEN 4P USB3.0 DisplayPORT Dual View KVMP SW
ATEN 4P USB3.0 DisplayPORT Dual View KVMP SW, 4096 x 2160 pixels, Ethernet LAN, 4K Ultra HD, 6.125 W, Black
Availability:: Arriving soon
The ATEN CS1944DP desktop KVM switch helps organize your desktop. Especially when managing a multimedia workstation at a large organization, CS1944DP provides you with instant access to two or four computers, all through a single USB keyboard, USB mouse and two DisplayPort monitors.1x 4-Port USB 3.0 4K DisplayPort Dual Display KVMP™ Switch8x LIN5-20K1-K13G DisplayPort 1.2 Cables4x LIN6-11C1-E12G USB 3.0 Cables8x LIN5-0205-21CG/LIN5-0205-21DG Audio Cables1x LIN2-418K-E12G Power Adapter1x User Instructions
| Ports & interfaces | |
|---|---|
| Number of computers controlled | 4 |
| Keyboard port type | USB |
| Mouse port type | USB |
| Video port type | DisplayPort |
| DisplayPorts quantity | 10 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-B ports quantity | 4 |
| Console ports | 3.5mm headphone,3.5mm mic,DisplayPort,USB A |
| Console USB ports quantity | 2 |
| USB hub | Y |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A hub ports quantity | 2 |
| Audio connections | Y |
| Headphone outputs | 6 |
| Number of microphone inputs | 6 |
| DC-in jack | Y |
| Network | |
| Ethernet LAN | Y |
| Ethernet LAN (RJ-45) ports | 1 |
| Performance | |
| HD type | 4K Ultra HD |
| Maximum resolution | 4096 x 2160 |
| Video bandwidth | 60 |
| Scan interval | 1,99 |
| Firmware upgradeable | Y |
| Design | |
| Product colour | Black |
| Housing material | Metal |
| LED indicators | Y |
| Push button | Y |
| Hot keys | Y |
| Display | |
| Built-in display | N |
| Power | |
| Power source | DC |
| Input voltage | 12 |
| Power consumption (typical) | 6.125 |
| Sustainability | |
| Compliance certificates | RoHS |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 50 |
| Storage temperature (T-T) | -20 - 60 |
| Operating relative humidity (H-H) | 0 - 80 |
| Weight & dimensions | |
| Width | 156.6 |
| Depth | 335 |
| Height | 44 |
| Weight | 3460 |
| Packaging data | |
| Package width | 116 |
| Package depth | 540 |
| Package height | 233 |
| Package weight | 4205 |
| Packaging content | |
| Cables included | Audio (3.5mm),DisplayPort,USB |
| Manual | Y |
| AC adapter included | Y |
| Logistics data | |
| Master (outer) case net weight | 10380 |
| Harmonized System (HS) code | 85176200 |
| Master (outer) case width | 375 |
| Master (outer) case length | 565 |
| Master (outer) case height | 258 |
| Master (outer) case gross weight | 13200 |
| Products per master (outer) case | 3 |
