be quiet! Pure Power 12 M power supply unit 850 W 20+4 pin ATX ATX Black
(0 review)Add your review
€189,76

be quiet! Pure Power 12 M, 850 W, 100 - 240 V, 900 W, 50 - 60 Hz, 12 / 6 A, Active

Availability: Arriving Soon
EAN:4260052189498Categories:PowerTags:

EXCEPTIONAL QUIET, SUPERIOR FEATURESPure Power 12 M 850W is ATX 3.1 compliant and PCIe 5.0 compatible and offers peerless dependability with best-in-class features. Pure Power 12 M 850W offers the best combination of features with outstanding compatibility.80 PLUS® GOLD CERTIFIEDVery high operating efficiencyPure Power 12 M 850W is certified 80 PLUS Gold with an outstanding efficiency rating of up to 93.2%. The most compelling benefit: lower power consumption, consequently lower costs, and above all a cooler as well as quieter operation. Pure Power 12 M 850W is always the correct choice for quiet systems and gaming PCs!FUTURE-PROOF YOUR SYSTEMFulfills all ATX 3.1 specificationsPure Power 12 M 850W is an ATX 3.1 PSU and comes with both native integration of the 12V-2x6 connector for next-generation PCIe 5.1 graphics cards, and PCIe 6+2-pin connectors for support of current-gen GPUs. This makes the PSU extremely versatile and the perfect choice for present high-end systems and the ones to come.THE NEW STANDARD OF POWERFor massive transient loadsPure Power 12 M offers 850W of continuous power with 2 independent 12V rails. Even if the graphics card demands excessive power for a short time: Pure Power 12 M 850W handles power excursions up to double its rated power with ease. This ensures reliable operation with the next generation of processors and graphics cards.UNPRECEDENTED SILENT OPERATIONAchieved with a silence-optimized be quiet! fanThe exceptionally silent 120mm be quiet! fan is temperature-controlled to strike the best balance between effective cooling and quietness. Airflow-optimized fan blades reduce turbulence, enabling best-in-classquiet functionality. HIGH-CLASS TECHNOLOGIESRock-solid stabilityWith its LLC topology Pure Power 12 M 850W provides a best-in-class voltage regulation and efficiency. That makes it perfect for building or upgrading very quiet systems as well as gaming and media creation PCs.MODULAR CABLESUtmost convenience and compatibilityThanks to their modularity, all unnecessary cables in the system are left out. Pure Power 12 M 850W simplifies cable management and routing for a tidy-looking system. A smoother airflow results from the uncluttered layout of the system, which means lower noise and temperatures inside the case.

Power
Total power850
Peak power900
AC input voltage100 - 240
AC input frequency50 - 60
Input current12 / 6
Power factor0.98
Power Factor Correction (PFC) typeActive
Combined power (+3.3V)120
Combined power (+12V)850
Combined power (+5V)120
Combined power (-12V)3.6
Combined power (+5Vsb)15
Max output current (+3.3V)22
Max output current (+12V)70.9
Max output current (+12V1)40
Max output current (+12V2)36
Max output current (+5V)22
Max output current (-12V)0.3
Max output current (+5Vsb)3
Efficiency93.2
Power Good signal delay range100 - 150
Power protection featuresOver current,Over power,Over voltage,Overheating,Short circuit
Ports & interfaces
Motherboard power connector20+4 pin ATX
Motherboard power cable length550
Number of SATA power connectors6
Number of PATA power connectors2
SATA power cable length500,600,650,800,950
Peripheral (Molex) power connectors (4-pin)1
Peripheral (Molex) power cable length550
EPS power connector (8-pin)Y
EPS power connector (4+4 pin)Y
PCI Express power connectors (6+2 pin)4
ATX power connector (20+4 pin)Y
PCI Express connectorY
Cabling typeFully-Modular
Performance
80 PLUS certification80 PLUS Gold
PurposePC
Power supply unit (PSU) form factorATX
ATX version3.1
EPS version2.92
Noise level25.7
Mean time between failures (MTBF)100000
Design
Product colourBlack
Cooling typeActive
Fan diameter120
Number of fans1
Fan locationTop
On/off switchY
Operational conditions
Operating temperature (T-T)0 - 40
Packaging content
Cables includedPATA,PCIe,Peripheral (Molex),SATA
Certificates
Compliance certificatesRoHS
Weight & dimensions
Width160
Depth150
Height86
Packaging data
Package typeBox
Technical details
Sustainability complianceY
Sustainability certificatesENERGY STAR,ErP
Logistics data
Warranty period10
Other features
Screws includedY
Number of screws5
Cable ties includedY
Noise level (silent mode, <30%)9.4
Noise level (quiet mode, 50%)9.5
Noise level (full-load mode, 100%)25.7
