GIGABYTE B550M K Motherboard - AMD Ryzen 5000 CPUs, up to 4733MHz DDR4, 1xPCIe 4.0 + 1xPCIe 3.0 M.2, 1GbE LAN, USB 3.2 Gen 1

€87,08

GIGABYTE B550M K Motherboard - AMD Ryzen 5000 CPUs, up to 4733MHz DDR4, 1xPCIe 4.0 + 1xPCIe 3.0 M.2, 1GbE LAN, USB 3.2 Gen 1, AMD, Socket AM4, AMD Ryzen 3000 Series, AMD Ryzen 4000 Series, AMD Ryzen 5000 Series, Socket AM4, DDR4-SDRAM, 128 GB

Availability:: Arriving soon

Add to Cart

Add to wishlist

Compare

EAN:4719331852764Categories:Hardware Components

Elevate your computing experience with GIGABYTE's renowned motherboard series: AORUS, AERO, and GIGABYTE. Featuring innovative designs and advanced features, these boards offer exceptional performance and reliability. Whether you're a gamer, content creator, or professional, our series cater to your needs, ensuring uncompromising quality and cutting-edge

Processor
Processor manufacturer	AMD
Processor socket	Socket AM4
Compatible processor series	AMD Ryzen 3000 Series,AMD Ryzen 4000 Series,AMD Ryzen 5000 Series
Supported processor sockets	Socket AM4
Memory
Supported memory types	DDR4-SDRAM
Number of memory slots	4
Memory slots type	DIMM
Memory channels	Dodeca-channel
ECC сompatibility	ECC & non-ECC
Supported memory clock speeds	4733,4600,4400,4266,4133,4000,3866,3733,3600,3466,3400,3200,2933,2667,2400,2133
Supported memory clock speed (max)	4733
Maximum internal memory	128
Unbuffered memory	Y
Maximum internal memory per slot	32
Storage controllers
Supported storage drive types	HDD & SSD
Supported storage drive interfaces	M.2,SATA
Number of HDDs supported	2
Number of storage drives supported	6
RAID support	Y
RAID levels	0,1,10
Graphics
Parallel processing technology support	Not supported
Maximum resolution	5120 x 2880
HDCP	Y
DirectX version	12.0
Internal I/O
USB 2.0 connectors	1
USB 3.2 Gen 1 (3.1 Gen 1) connectors	1
Number of SATA III connectors	4
Front panel audio connector	Y
Front panel connector	Y
ATX Power connector (24-pin)	Y
CPU fan connector	Y
Number of CPU fan connectors	1
Number of chassis fan connectors	1
EPS power connector (8-pin)	Y
Number of EPS power connectors (8-pin)	1
TPM connector	Y
12V power connector	Y
Rear panel I/O ports
USB 2.0 ports quantity	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
Ethernet LAN (RJ-45) ports	1
PS/2 ports quantity	1
HDMI ports quantity	1
HDMI version	2.1
DisplayPorts quantity	1
DisplayPort version	1.4
Headphone outputs	1
Line-in	Y
Microphone in	Y
Network
Ethernet LAN	Y
Ethernet interface type	Gigabit Ethernet
LAN controller	Realtek RTL8111H
Wi-Fi	N
Features
Motherboard chipset	AMD B550
Audio chip	Realtek ALC897
Audio output channels	7.1
Product colour	Brown
PC health monitoring	FAN,Temperature,Voltage
Component for	PC
Motherboard form factor	Micro ATX
Motherboard chipset family	AMD
Cooling type	Passive
Power source type	ATX
Windows operating systems supported	Windows 10 x64,Windows 11 x64
Expansion slots
PCI Express x1 (Gen 3.x) slots	1
PCI Express x16 (Gen 4.x) slots	1
Number of M.2 (M) slots	2
1st M.2 largest key size	2280
1st M.2 highest PCI Express generation	4.0
2nd M.2 largest key size	2280
2nd M.2 highest PCI Express generation	3.0
BIOS
BIOS type	UEFI AMI
BIOS memory size	128
ACPI version	5.0
Clear CMOS jumper	Y
Desktop Management Interface (DMI) version	2.7
System Management BIOS (SMBIOS) version	2.7
Logistics data
Country of origin	China
Products per shipping (inner) case	1
Battery
Battery weight	3
Lithium weight per battery	0.07
Number of battery cells	1
Battery technology	Lithium-Manganese Dioxide (LiMnO2)
Battery type	CR2032
Packaging data
Package width	265
Package depth	265
Package height	54
Package weight	837
Weight & dimensions
Width	244
Depth	244
Height	35
Packaging content
Batteries included	Y
Screws included	Y
Bundled software	Norton® Internet Security (OEM version) LAN bandwidth management software
Technical details
Warranty period	3
