FSP HP2-600 power supply unit 600 W 24-pin ATX ATX Black
(0 review)Add your review
€90,77

FSP HP2-600, 600 W, 200 - 240 V, 50 - 60 Hz, 4.5 A, Active, 100 W

Availability: Arriving Soon
EAN:4713224525957Categories:PowerTags:

The new Hydro K PRO PSUs comply fully ATX12 v2.52 standard and the latest safety 62368 regulation as well and comes with high-grade ribbon cables, give your PC a polished look. The Hydro K PRO series is designed as a powerful single +12V rail that continually delivers maximum performance for the most demanding graphic cards, while FSP’s custom DC-DC design provides safety and power efficiency. Besides, with an 230V 80 Plus® rating, delivers over 88% high efficiency and low noise levels thanks to its hydraulic bearing fan design, where a large 120mm fan takes care of cooling duties when required, making it excellent for situations that are sensitive to size and noise.Up-to-date Circuit DesignA dual forward topology integrated with active PFC and PWM technology and double EMI filter delivers full power and enhance stability to your system.Stable DC to DC Output QualityDC to DC modules with low ripple noise and prolongs system lifetime.Double Layer EMI FilterTo reduce electromagnetic interference and suppress noise.Low Noise, Less HeatHydro K PRO series is equipped with the 120mm hydraulic bearing fan (HYB) which makes optimum cooling and reduces noise. Moreover, the lifespan of fan is longer than standard one.+12V Single Rail DesignDesigned for power-intensive VGA cards, provides strong power to any overloading condition.80 Plus® Bronze CertificationWith an 230V 80 Plus® rating, Hydro K PRO series delivers over 88% high efficiency.Energy Related ErP/Eup 2013Green Power! The total AC power consumption less than 5Vsb rail to meet the new EU Regulation ErP 2013 for modern systems.

Power
Total power600
AC input voltage200 - 240
AC input frequency50 - 60
Input current4.5
Power factor0.9
Power Factor Correction (PFC) typeActive
Combined power (+3.3V)100
Combined power (+12V)600
Combined power (+5V)100
Combined power (-12V)3.6
Combined power (+5Vsb)12.5
Max output current (+3.3V)20
Max output current (+12V)50
Max output current (+5V)20
Max output current (-12V)0.3
Max output current (+5Vsb)2.5
Efficiency88
Power protection featuresOver current,Over power,Over voltage,Short circuit
Ports & interfaces
Motherboard power connector24-pin ATX
Motherboard power cable length500
Number of SATA power connectors5
Peripheral (Molex) power connectors (4-pin)2
PCI Express power connectors (6+2 pin)2
CPU power connector (4+4 pin)Y
CPU power cable length850
Floppy drive power connector1
Floppy disk drive connectorY
Cabling typeNon-Modular
Performance
80 PLUS certification80 PLUS Bronze
PurposePC/server
Power supply unit (PSU) form factorATX
ATX version3.0
Bearing technologyHYB
Design
Product colourBlack
Cooling typeActive
Fan diameter120
Number of fans1
Fan locationTop
On/off switchY
Packaging content
Cables includedCPU,PCIe,Peripheral (Molex),SATA
Weight & dimensions
Width140
Depth150
Height86
Packaging data
Package typeBox
