FSP Clippers RT 1K uninterruptible power supply (UPS) Double-conversion (Online) 1 kVA 1000 W
FSP Clippers RT 1K, Double-conversion (Online), 1 kVA, 1000 W, Sine, 110 V, 300 V
Availability: Arriving Soon
FSP Clippers RT Series Clippers series is a premium featured online double conversion UPS with Rack/Tower design and high efficiency to reduce customer‘s total cost of ownership. The internal hot-swappable battery increases system reliability and reduces MTTR; the parallel function is designed for future equipment expansion. Its special firmware design can adapt to various applications like laser printers and ultrasound devices and supports long backup time with battery monitoring.
| Features | |
|---|---|
| UPS topology | Double-conversion (Online) |
| Output power capacity | 1 |
| Output power | 1000 |
| Waveform | Sine |
| Input operation voltage (min) | 110 |
| Input operation voltage (max) | 300 |
| Input frequency | 40/70 |
| Output operation voltage (min) | 208 |
| Output operation voltage (max) | 240 |
| Output frequency | 46/64 |
| Output voltage regulation | 1 |
| Response time | 4 |
| Number of input phases | 1 |
| Power factor | 0.99 |
| Crest factor | 3:1 |
| Emergency Power Off (EPO) | Y |
| Total Harmonic Distortion (THD) (linear load) | 2 |
| Total Harmonic Distortion (THD) (non-linear load) | 4 |
| Noise level | 50 |
| Surge protection | Y |
| Audible alarm(s) | Y |
| Audible alarm modes | Alarm when on battery,Fault,Low battery alarm,Overload alarm |
| Ports & interfaces | |
| AC outlet types | C13 coupler |
| USB port | Y |
| USB 2.0 ports quantity | 1 |
| USB port type | USB Type-B |
| Serial interface | Y |
| Serial interface type | RS-232 |
| Emergency Power Off (EPO) connector | Y |
| Battery | |
| Battery capacity | 9 |
| Battery voltage | 12 |
| Number of battery cells | 2 |
| Typical backup time at full load | 33 |
| Battery recharge time | 3 |
| Hot-swap battery | Y |
| Design | |
| Form factor | Rackmount/Tower |
| Cooling type | Active |
| Built-in fan | Y |
| Product colour | Black |
| Control type | Buttons |
| Display type | LCD |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 |
| Operating relative humidity (H-H) | 20 - 90 |
| Certificates | |
| Compliance certificates | CE |
| Certification | EMC EN62040-2 C2 |
| Sustainability | |
| Sustainability compliance | Y |
| Weight & dimensions | |
| Width | 438 |
| Depth | 410 |
| Height | 88 |
| Weight | 11600 |
| Logistics data | |
| Harmonized System (HS) code | 85078000 |
| Other features | |
