FSP HEXA 85+ PRO power supply unit 550 W 24-pin ATX ATX Black
FSP HEXA 85+ PRO, 550 W, 100 - 240 V, 50 - 60 Hz, 7.5 - 3 A, Active, 100 W
Availability: Arriving Soon
HEXA 85+ PRO series is ATX PSU certified with 80 PLUS® Bronze, featured with DC to DC module and +12V single-rail design, taken with full Japanese capacitors and quiet 120mm silent fan, built-in with complete protections: OCP, OVP, SCP, OPP, and approved by the latest global safety regulation 62368 . Besides, the all black-cable design saves your system an optimal airflow space that allows for easy cable management and a polished look. HEXA 85+ PRO series power ranges from 350W, 450W, 550W to 650W to satisfy various needs.80 Plus® Bronze CertificationHEXA 85+ Pro Series, 80 PLUS ® bronze certified, saves energy through its high efficiency up to 85%.All Black Round CablesIt gives your system a superior look than any other entry level power supplies.Stable DC to DC Output QualityHEXA85+ PRO series applies DC to DC modules to improve the reliability for greater compatibility as well as low ripple noise to reduce interference of system components for a prolonged system lifetime.+12V Single Rail DesignDesigned for power-intensive VGA cards, no problems to any overloading condition.Optimal CoolingHEXA 85+ PRO series comes with a 120mm quiet fan and a highly efficient ventilation fan guard to guarantee low noise operations without compromising its cooling efficiency.Japanese Electrolytic CapacitorsJapanese electrolytic capacitors ensures safety on spare parts for prolonged lifespan and reliability.Supports High-end MotherboardFor gaming enthusiast, the Hexa 85+ PRO 550W featured dual CPU power connectors for high-end motherboards and stable CPU power delivery.Energy Related ErP/Eup 2013Green Power! The total AC power consumption less than 5Vsb rail to meet the new EU Regulation ErP 2013 for modern systems.
| Power | |
|---|---|
| Total power | 550 |
| AC input voltage | 100 - 240 |
| AC input frequency | 50 - 60 |
| Input current | 7.5 - 3 |
| Power Factor Correction (PFC) type | Active |
| Combined power (+3.3V) | 100 |
| Combined power (+12V) | 550 |
| Combined power (+5V) | 100 |
| Combined power (-12V) | 3.6 |
| Combined power (+5Vsb) | 12.5 |
| Max output current (+3.3V) | 20 |
| Max output current (+12V) | 45.83 |
| Max output current (+5V) | 20 |
| Max output current (-12V) | 0.3 |
| Max output current (+5Vsb) | 2.5 |
| Hold time | 17 |
| Efficiency | 85 |
| Power protection features | Over current,Over power,Over voltage,Short circuit |
| Ports & interfaces | |
| Motherboard power connector | 24-pin ATX |
| Number of SATA power connectors | 8 |
| Peripheral (Molex) power connectors (4-pin) | 2 |
| PCI Express power connectors (6+2 pin) | 2 |
| CPU power connector (4+4 pin) | Y |
| ATX Power connector (24-pin) | Y |
| Floppy drive power connector | 1 |
| Floppy disk drive connector | Y |
| PCI Express connector | Y |
| Cabling type | Non-Modular |
| Performance | |
| 80 PLUS certification | 80 PLUS Bronze |
| Purpose | PC/server |
| Power supply unit (PSU) form factor | ATX |
| ATX version | 2.5 |
| EPS version | 2.92 |
| Bearing technology | Sleeve |
| Design | |
| Product colour | Black |
| Cooling type | Active |
| Fan diameter | 120 |
| Number of fans | 1 |
| On/off switch | Y |
| Packaging content | |
| Cables included | CPU,PCIe,Peripheral (Molex),SATA |
| Weight & dimensions | |
| Width | 140 |
| Depth | 150 |
| Height | 86 |
| Weight | 1328 |
| Logistics data | |
| Harmonized System (HS) code | 84733020 |
