LevelOne GEP-1221 network switch Unmanaged Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black
LevelOne GEP-1221, Unmanaged, Gigabit Ethernet (10/100/1000), Power over Ethernet (PoE), Rack mounting
Availability: Arriving Soon
The GEP-1221 switch provides 10 port 10/100/1000M ports with 2 port SFP. It is designed for easy installation and high performance in an environment where traffic is on the network and the number of users increases continuously. It consists of 8 PSE/PoE ports. That can solve the limitation of the power outlet location and offer the system designer a flexible solution to locate the network device everywhere.The device size is specifically designed for medium to large workgroups. The Switch can be installed where space is limited; moreover it provides smooth network migration and easy upgrade to network capacity. The PoE switch can be rack-mount on 19” cabinet.
| Management features | |
|---|---|
| Switch type | Unmanaged |
| Ports & interfaces | |
| Basic switching RJ-45 Ethernet ports quantity | 10 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Gigabit Ethernet (copper) ports quantity | 10 |
| SFP module slots quantity | 2 |
| Network | |
| Networking standards | IEEE 802.3,IEEE 802.3ab,IEEE 802.3af,IEEE 802.3at,IEEE 802.3i,IEEE 802.3u,IEEE 802.3x,IEEE 802.3z |
| 10G support | N |
| Auto MDI/MDI-X | Y |
| Ethernet LAN data rates | 1000 |
| Auto-negotiation | Y |
| Data transmission | |
| Switching capacity | 22 |
| MAC address table | 4000 |
| Design | |
| Rack mounting | Y |
| Stackable | N |
| Product colour | Black |
| LED indicators | Y |
| Performance | |
| Internal memory | 2 |
| Fanless | Y |
| Power | |
| Power source | AC |
| Power supply included | Y |
| AC input voltage | 100 - 240 |
| Power consumption (typical) | 10 |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | Y |
| Power over Ethernet (PoE) power per port | 30 |
| Total Power over Ethernet (PoE) budget | 150 |
| Operational conditions | |
| Operating temperature (T-T) | 5 - 40 |
| Storage temperature (T-T) | -40 - 70 |
| Operating relative humidity (H-H) | 5 - 90 |
| Storage relative humidity (H-H) | 5 - 90 |
| Weight & dimensions | |
| Width | 250 |
| Depth | 150 |
| Height | 40 |
| Weight | 1400 |
| Packaging content | |
| Quick start guide | Y |
| Logistics data | |
| Harmonized System (HS) code | 85176990 |
