MSI N3050I ECO motherboard BGA 1170 mini ITX
MSI N3050I ECO, Intel, BGA 1170, Intel® Celeron®, N3050, DDR3-SDRAM, DDR3L-SDRAM, 8 GB
Availability:: Arriving soon
- Intel® Celeron® N3050 Processor Onboard- Supports DDR3-1600 Memory- USB 3.0 + SATA 6Gb/s- ECO Performance: 100% performance, 24/7 stable and green- Military Class 4: Top Quality & Stability- 4K UHD Support: Ultra-high Definition Visual Experience- Fast Boot: Quickly Boot Up & Enter OS in A Few Seconds- M-Flash: Simply Update & Backup Your BIOS- Live Update 6: Easily Update The Latest BIOS & DriversMilitary Class 4Military Class 4 is the next step in high quality components. The Hi-c Cap, Super Ferrite Choke and Solid CAPs will make sure that your PC runs more stable under extreme gaming conditions.DARK CHOKEDark Choke uses the special core design and allows the Dark Choke to run at a lower temperature with higher capacity and better power efficiency and stability.SOLID CAPWith their aluminum core design, Dark CAP`s have been a staple in high-end design mainboard designs and provides lower Equivalent Series Resistance (ESR) as well as its over-10-year lifespan.Military Class essentialsThe core of Military Class 4 is based on the essentials which increase your stability in the worst conditions. The humidity protection and high temperature protection ensure your system surviving each environment, no matter how harsh. The new structure of the PCB limits EMI radiation. On top of that all the connectors have ESD protection in order to prevent short circuit. Humidity ProtectionThe latest Gen 4 Fabric PCB helps to against moisture cause by some humid conditions and environments.ESD ProtectionAnti-ESD ICs and fuses onboard helps to totally protect your motherboard from electrostatic damage.EMI ProtectionThe optimized EMI-proof design helps to keep users safe when during a long-time computer operation. HIGH Temperature ProtectionCertificated Military Class 4 components help to work stable under some extreme conditions.M-FlashCompared to common motherboards which need extra BIOS chips, MSI's M-Flash has a double advantage which doesn't need extra components and secondly, all your BIOS data will be saved in the USB drive. The stored data does not only have backup and upgrade function, moreover, it can also be seen as a portable BIOS chip which is actually able to boot up your PC.- Backup/Restore Your BIOS to/from Any USB Flash Disk- Avoid Unnecessary Repair Due to Accident Failures During The Upgrading Process- Earn more BIOS Lifespan by Reducing Unnecessary Rewriting ProcessUSB 3.0Compared to the 480Mbps provided by traditional USB 2.0, the all-new USB 3.0's 5Gb/s offers 10 times the transfer bandwidth, so transferring a Blu-ray movie takes less than one minute.- 10X Faster Than USB 2.0- Up to 5Gb/s Data Transfer Bandwidth- Boost Transfer Rate Between Your PC and External Storage DevicesSATA 6Gb/sSATA 6Gb/s provides double the bandwidth of traditional SATA 3Gb/s, and increases the data transfer rate between your motherboard and internal storage devices, such as 7200RPM HDDs, 10000RPM HDDs and SSDs. It's also the current trend for upcoming high-speed internal storage devices to break the existing bottleneck of a PC's performance.- 2X Faster Than SATA 3Gb/s- Up to 6Gb/s Data Transfer Bandwidth- Unleash True Performance of New HDDs/SSDsLIVE UPDATE 6MSI Live Update is renewed! Our popular software automatically downloads and installs the latest drivers, BIOS and software. Rest assured while your system is always configured using the latest software so you get the maximum performance and stability.FAST BOOTNo more seamless waiting for your O/S to be loaded! MSI Fast Boot helps to make your system boot lightning fast. MSI Fast Boot also features a GO2BIOS button. Simply click it to restart your PC and go straight to the system BIOS.HDMIEnjoy the awesome HD video playback now! MSI motherboards that equip with HDMI port(s) supports the latest and the most innovative signal outputs to provide an unprecedented visual experience.
| Processor | |
|---|---|
| Processor manufacturer | Intel |
| Processor socket | BGA 1170 |
| Compatible processor series | Intel Celeron |
| Processor model | N3050 |
| Processor cores | 2 |
| Memory | |
| Supported memory types | DDR3-SDRAM,DDR3L-SDRAM |
| Number of memory slots | 2 |
| Memory slots type | SO-DIMM |
| Memory channels | Dual-channel |
| Supported memory clock speeds | 1333,1600 |
| Maximum internal memory | 8 |
| Storage controllers | |
| Supported storage drive interfaces | SATA III |
| Graphics | |
| Maximum resolution | 3840 x 2160 |
| Internal I/O | |
| USB 2.0 connectors | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) connectors | 1 |
| Number of SATA III connectors | 2 |
| Front panel audio connector | Y |
| ATX Power connector (24-pin) | Y |
| CPU fan connector | Y |
| Chassis intrusion connector | Y |
| Serial port headers | 2 |
| Rear panel I/O ports | |
| USB 2.0 ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| Ethernet LAN (RJ-45) ports | 1 |
| PS/2 ports quantity | 2 |
| VGA (D-Sub) ports quantity | 1 |
| HDMI ports quantity | 1 |
| Network | |
| Ethernet LAN | Y |
| Ethernet interface type | Gigabit Ethernet |
| LAN controller | Realtek RTL8111G |
| Features | |
| Audio chip | Realtek ALC887 |
| Audio output channels | 7.1 |
| Component for | PC |
| Motherboard form factor | Mini ITX |
| Motherboard chipset family | Intel |
| Power source type | ATX |
| Expansion slots | |
| PCI Express x1 (Gen 2.x) slots | 1 |
| BIOS | |
| Clear CMOS jumper | Y |
| Processor special features | |
| Intel® Anti-Theft Technology (Intel® AT) | N |
| Intel® Clear Video HD Technology (Intel® CVT HD) | Y |
| Intel® Virtualization Technology (Intel® VT) | VT-x |
| Intel Trusted Execution Technology | N |
| Intel Rapid Storage Technology | N |
| Intel® AES New Instructions (Intel® AES-NI) | Y |
| Intel® High Definition Audio (Intel® HD Audio) | Y |
| Conflict-Free | Y |
| Intel® Wireless Display (Intel® WiDi) | Y |
| Intel® Turbo Boost Technology | N |
| Intel® Hyper Threading Technology (Intel® HT Technology) | N |
| Intel VT-x with Extended Page Tables (EPT) | Y |
| Intel 64 | Y |
| Idle States | Y |
| Enhanced Intel SpeedStep Technology | Y |
| Thermal Monitoring Technologies | Y |
| Intel® Identity Protection Technology (Intel® IPT) | Y |
| Intel Stable Image Platform Program (SIPP) | N |
| Intel® Small Business Advantage (Intel® SBA) | N |
| Intel® Smart Response Technology | N |
| Intel® Secure Key | Y |
| Execute Disable Bit | Y |
| Intel® OS Guard | N |
| Intel® Quick Sync Video Technology | Y |
| Intel Clear Video Technology | Y |
| Intel® Insider™ | N |
| Intel® InTru™ 3D Technology | N |
| Intel Virtualization Technology (VT-x) | Y |
| Intel Virtualization Technology for Directed I/O (VT-d) | N |
| Weight & dimensions | |
| Width | 170 |
| Depth | 170 |
| Other features | |
| Intel® vPro™ Platform Eligibility | N |
| Processor frequency | 1.16 |
