UbiQuiti UniFi 5G Max Outdoor Router U5G-MAX-OUTDOOR (1 Jahr Garantie)
Features Ubiquiti UniFi 5G Max Outdoor
Outdoor 5G gateway with 3.4 Gbps download (NSA) / 1.8 Gbps (SA)Support for nano SIM + nano SIM/eSIM (dual slot)1× 2.5 GbE WAN/LAN port6 built-in antennas, of which 2× high-gain (9 dBi)IPX6 weatherproof (IP67 with cable gland)Operating temperature from -40 to 65 °CFull management via UniFi Network (v10.0.162+)
Super fast and stable outdoor connectivity
With support for 5G NR (SA and NSA) and LTE Advanced, the Ubiquiti UniFi 5G Max Outdoor offers high data speeds and wide band support for deployments across Europe. The maximum download speed is up to 3.4 Gbps over 5G NSA and up to 1.8 Gbps over 5G SA. This makes the device suitable as a primary internet connection at outdoor locations or as a redundant WAN connection for critical networks.
The six integrated antennas, including two high-gain antennas of 9 dBi for downlink, ensure optimal signal reception. This keeps the connection stable, even at greater distances to the transmission tower or in challenging RF environments.
Adoption via UniFi Cloud Gateway or UniFi Gateway
The UniFi 5G Max Outdoor only functions in combination with a UniFi Cloud Gateway or UniFi Gateway. Standalone use is not possible. Adoption and management are done via UniFi Network or the UniFi mobile app.
For most installations, LAN adoption offers the most flexibility. You connect the 2.5 GbE port to the LAN of your UniFi Gateway. This gives freedom in physical placement and cabling, while maintaining remote VPN access via Teleport on most mobile networks.
WAN adoption is recommended when your mobile carrier assigns a public IP address and you need remote access to services behind your Cloud Gateway, such as a VPN server. For WAN adoption, connect the UniFi 5G Max Outdoor to a PoE injector or to a reconfigured PoE WAN port of your Cloud Gateway. You then complete the adoption via UniFi Network or the UniFi mobile app.
Designed for extreme conditions
The aluminum housing is resistant to severe weather influences. The device is rated IPX6 as standard and IP67 is achieved with the included cable gland. Thanks to the wide temperature range from -40 to 65 °C, use in cold winters and warm summers is no problem.
The polycarbonate parts are UV-resistant and designed for long-term outdoor installation. With the included wall and pole holder you can easily attach the Ubiquiti UniFi 5G Max Outdoor to facades, masts or technical structures.
Seamless integration into UniFi
Within UniFi Network you centrally manage your WAN priorities, failover policy, monitoring and notifications. This makes the gateway suitable for redundant WAN configurations, mobile backup connections or fully mobile Internet applications in remote locations.
The 2.5 GbE port ensures that the available 5G bandwidth is passed on to your UniFi Gateway or switch without bottlenecks.
Package contents
- Ubiquiti UniFi 5G Max Outdoor
- Pole and wall mounting kit
- Kabelgland (for IP67 sealing)
- Quick start guide
Availability: In stock
Features Ubiquiti UniFi 5G Max Outdoor
Outdoor 5G gateway with 3.4 Gbps download (NSA) / 1.8 Gbps (SA)Support for nano SIM + nano SIM/eSIM (dual slot)1× 2.5 GbE WAN/LAN port6 built-in antennas, of which 2× high-gain (9 dBi)IPX6 weatherproof (IP67 with cable gland)Operating temperature from -40 to 65 °CFull management via UniFi Network (v10.0.162+)
Super fast and stable outdoor connectivity
With support for 5G NR (SA and NSA) and LTE Advanced, the Ubiquiti UniFi 5G Max Outdoor offers high data speeds and wide band support for deployments across Europe. The maximum download speed is up to 3.4 Gbps over 5G NSA and up to 1.8 Gbps over 5G SA. This makes the device suitable as a primary internet connection at outdoor locations or as a redundant WAN connection for critical networks.
The six integrated antennas, including two high-gain antennas of 9 dBi for downlink, ensure optimal signal reception. This keeps the connection stable, even at greater distances to the transmission tower or in challenging RF environments.
Adoption via UniFi Cloud Gateway or UniFi Gateway
The UniFi 5G Max Outdoor only functions in combination with a UniFi Cloud Gateway or UniFi Gateway. Standalone use is not possible. Adoption and management are done via UniFi Network or the UniFi mobile app.
For most installations, LAN adoption offers the most flexibility. You connect the 2.5 GbE port to the LAN of your UniFi Gateway. This gives freedom in physical placement and cabling, while maintaining remote VPN access via Teleport on most mobile networks.
WAN adoption is recommended when your mobile carrier assigns a public IP address and you need remote access to services behind your Cloud Gateway, such as a VPN server. For WAN adoption, connect the UniFi 5G Max Outdoor to a PoE injector or to a reconfigured PoE WAN port of your Cloud Gateway. You then complete the adoption via UniFi Network or the UniFi mobile app.
Designed for extreme conditions
The aluminum housing is resistant to severe weather influences. The device is rated IPX6 as standard and IP67 is achieved with the included cable gland. Thanks to the wide temperature range from -40 to 65 °C, use in cold winters and warm summers is no problem.
The polycarbonate parts are UV-resistant and designed for long-term outdoor installation. With the included wall and pole holder you can easily attach the Ubiquiti UniFi 5G Max Outdoor to facades, masts or technical structures.
Seamless integration into UniFi
Within UniFi Network you centrally manage your WAN priorities, failover policy, monitoring and notifications. This makes the gateway suitable for redundant WAN configurations, mobile backup connections or fully mobile Internet applications in remote locations.
The 2.5 GbE port ensures that the available 5G bandwidth is passed on to your UniFi Gateway or switch without bottlenecks.
Package contents
- Ubiquiti UniFi 5G Max Outdoor
- Pole and wall mounting kit
- Kabelgland (for IP67 sealing)
- Quick start guide
Specifications
| Certificates | Compliance certificates CE, GCF, PTCRB |
| Compliance certificates | CE, GCF, PTCRB |
| Device type | Cellular network modem |
| Housing material | Aluminium, Polycarbonate (PC) |
| LED indicators | Yes |
| Mounting | Pole/Wall mounting |
| Product colour | White |
| Reset button | Yes |
| Suitable for outdoor use | Yes |
| Ethernet LAN features | Ethernet LAN Yes Ethernet LAN interface type 2.5 Gigabit Ethernet |
| Ethernet LAN Yes | Ethernet LAN interface type 2.5 Gigabit Ethernet |
| Ethernet LAN | Yes |
| Ethernet LAN interface type | 2.5 Gigabit Ethernet |
| 3G standards | UMTS |
| 4G standard | LTE |
| 5G standard | Sub6 NR, Sub6 NSA, Sub6 SA |
| Data network | 3G, 4G, 5G |
| Number of SIM cards | 1 |
| Number of simultaneous SIM cards | 1 |
| Operational conditions | Operating relative humidity (H-H) 5 - 95 %Operating temperature (T-T) -40 - 65 °C |
| Operating relative humidity (H-H) 5 - 95 % | Operating temperature (T-T) -40 - 65 °C |
| Operating relative humidity (H-H) | 5 - 95 % |
| Operating temperature (T-T) | -40 - 65 °C |
| Performance | International Protection (IP) code IPX6, IP67 |
| International Protection (IP) code | IPX6, IP67 |
| Ports & interfaces | Ethernet LAN (RJ-45) ports 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| Power | Power source type PoE |
| Power source type | PoE |
| Vendor information | Brand Name Ubiquiti Warranty 2 Ã…r |
| Brand Name Ubiquiti | Warranty 2 Ã…r |
| Brand Name | Ubiquiti |
| Warranty | 2 Ã…r |
| Wireless LAN features | Wi-Fi No |
| Wi-Fi | No |
| Kategorier | Hovedkategori Network Underkategori Firewalls & Gateways Underkategori Cellular Network Devices |
| Hovedkategori | Network |
| Underkategori | Cellular Network Devices |
