Funktel IP base station FB4 IP TP
PoE Cat 5/6 radio base station for high-performance communication networks The FB4 IP PoE base station enables the implementation of high-performance DECT/IP communication networks for a wide range of circumstances and requirements. All wireless telephony functions of the central IP telephony system
Availability: In stock
["PoE Cat 5/6 radio base station for high-performance communication networks The FB4 IP PoE base station enables the implementation of high-performance DECT/IP communication networks for a wide range of circumstances and requirements. All wireless telephony functions of the central IP telephony system are supported via the base station. The DECT controller makes configuring the DECT network user-friendly and convenient. Thanks to integrated contacts, the widest possible range of technical installations can be connected to the FB4. With its DECT messaging information, the FB4 can be used to relay specific events or conditions for each contact, such as temperature measurement, level indication, door opening, motion sensors, etc. Features:", "12 channels", "10 voice channels (8 if DSS/IMS is installed)", "1 channel for synchronization, 1 carrier channel", "Supports Power over Ethernet (PoE) AND external power cable", "IEEE 802.3af PoE Class 1 (0.44W to 3.84W)", "LED status display", "Switching input (open or closed)", "Two ports for external antennas", "PoE AND external power cable, max. cable length 100 m Specifications:", "Dimensions: approx. 203 x 155 x 27 mm", "Temperature range: Operation: –10 ... +45 °C / Storage: –40 ... +85 °C", "Power supply: Power over Ethernet or separate power cable, 230 V", "Integrated contact connection for the transmission of certain events or states via switching contact, such as temperature measuring devices, level indicators, door contacts, motion detectors, etc", "Explosion protection: Protection for Ex zone 1, Ex zone 2", "Network connection: Selectable", "Ethernet TP", "Interface standard IEEE 802.3u – 100 Base TX Fast Ethernet (twisted copper cabling)", "IEEE 802.3 – 10BaseT Ethernet (twisted pair copper cabling)", "Network cable RJ45-8p, UTP Cat. 5 E (100 m max.)", "EIA/TIA-568 – 100 Ohm STP (100m max.)", "PoE (Power over Ethernet) IEEE 802.3af, performance class 1, powered via RJ45-8p pin (1, 2 and 3, 6)", "Phantom power via RX, TX, or powered via RJ45-8p pin (4, 5 and 7, 8), powered via unused double wires", "0.44...3.84W, 36...57V"]
Specifications
| Feature 1 | PoE Cat 5/6 radio base station for high-performance communication networks The FB4 IP PoE base station enables the implementation of high-performance DECT/IP communication networks for a wide range of circumstances and requirements. All wireless telephony functions of the central IP telephone |
| Feature 2 | 12 channels |
| Feature 3 | 10 voice channels (8 if DSS/IMS is installed) |
| Feature 4 | 1 channel for synchronization, 1 carrier channel |
| Feature 5 | Supports Power over Ethernet (PoE) AND external power cable |
| Feature 6 | IEEE 802.3af PoE Klasse 1 (0.44 W bis 3.84 W) |
| Feature 7 | LED-Statusanzeige |
| Feature 8 | Switching input (open or closed) |
| Feature 9 | Two ports for external antennas |
| Feature 10 | PoE AND external power cable, max. cable length 100 m specifications |
| Feature 11 | Dimensions: approx. 203 x 155 x 27 mm |
| Feature 12 | Temperature range: Operation: –10 ... +45 °C / Storage: –40 ... +85 °C |
| Feature 13 | Power supply: Power over Ethernet or separate power cable, 230 V |
| Feature 14 | Integrated contact connection for the transmission of certain events or states via switching contact, such as temperature measuring devices, level indicators, door contacts, motion detectors, etc |
| Feature 15 | Explosion protection: Protection for Ex zone 1, Ex zone 2 |
| Feature 16 | Network connection: Selectable |
| Feature 17 | Ethernet TP |
| Feature 18 | Interface standard IEEE 802.3u – 100 Base TX Fast Ethernet (twisted copper cabling) |
| Feature 19 | IEEE 802.3 – 10BaseT Ethernet (twisted pair copper cabling) |
| Feature 20 | Network cable RJ45-8p, UTP Cat. 5 E (100 m max.) |
| Feature 21 | EIA/TIA-568 – 100 Ohm STP (100 m max.) |
| Feature 22 | PoE (Power over Ethernet) IEEE 802.3af, performance class 1, powered via RJ45-8p pin (1, 2 and 3, 6) |
| Feature 23 | Phantom power via RX, TX, or powered via RJ45-8p pin (4, 5 and 7, 8), powered via unused double wires |
| Feature 24 | 0,44 ... 3,84 W, 36 ... 57 V |
