HPE Aruba Networking CX 5420 24p 10M/100M/1G Class4 PoE Module Switch
- HPE Aruba Networking CX 5420 24p 10M/100M/1G Class4 PoE Module Switch L3 Managed 24 x 10/100/1000 (PoE Class 4) front to back airflow plug in module PoE Class 4
Availability: In stock
Product description: HPE Aruba Networking CX 5420 24p 10M/100M/1G Class4 PoE Module - switch - 24 ports - Managed - plug-in module Device Type: Switch - 24 Ports - L3 - Managed Package type: Front to back airflow plug-in module 1U Subtype: Gigabit Ethernet Ports: 24 x 10/100/1000 (PoE Class 4) Power Over Ethernet (PoE): PoE Class 4 Routing protocol: IGMP, OSPF, VRRP, IGMPv3, MLDv2, ECMP, static IP routing, static IPv6 routing, RSTP, MSTP, STP Remote management protocol: RMON, SNMP 2c, SNMP 3, TFTP, SFTP, SSH, CLI, NTP Features: QoS, Layer 2 switching, layer 3 routing, VRRP support, UDLD, LACP, ToS, EQS, REST API interface, sFlow, Rapid PVST+, MVRP, BPDU, HPE SmartRate Compliance Standards: IEEE 802.1s, IEEE 802.3ad (LACP), IEEE 802.1D, IEEE 802.1w, IEEE 802.1p, IEEE 802.1ab (LLDP), IEEE 802.1Q, IEEE 802.1v, IEEE 802.1ak, IEEE 802.1AX, IEEE 802.1t, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3az, IEEE 802.3z Dimensions (W x D x H): 21.3 cm x 22.9 cm x 4.3 cm Weight: 762 g Manufacturer's Warranty: Limited Lifetime Warranty
Specifications
| Authentication method | Secure Shell (SSH), RADIUS, TACACS+ |
| Characteristics | QoS, Layer 2 switching, layer 3 routing, VRRP support, UDLD, LACP, ToS, EQS, REST API interface, sFlow, Rapid PVST+, MVRP, BPDU, HPE SmartRate |
| Device type | Switch - 24 ports - L3 - Managed |
| Compliance Standards | IEEE 802.1s, IEEE 802.3ad (LACP), IEEE 802.1D, IEEE 802.1w, IEEE 802.1p, IEEE 802.1ab (LLDP), IEEE 802.1Q, IEEE 802.1v, IEEE 802.1ak, IEEE 802.1AX, IEEE 802.1t, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3az, IEEE 802.3z |
| Packing type | Front to back airflow plug-in module 1U |
| Gates | 24 x 10/100/1000 (PoE Class 4) |
| Power Over Ethernet (PoE) | PoE Class 4 |
| Protocol for remote administration | RMON, SNMP 2c, SNMP 3, TFTP, SFTP, SSH, CLI, NTP |
| Routing protocol | IGMP, OSPF, VRRP, IGMPv3, MLDv2, ECMP, static IP routing, static IPv6 routing, RSTP, MSTP, STP |
| Subtype | Gigabit Ethernet |
| Interface | 24 x 10/100/1000 Base-T RJ-45 PoE Class 4 |
| Compliance Standards | IEC 62368-1: 2014 Second Edition, IEC 62368-1:2018 Third Edition, IEC 60825-1:2014, EN 60825-1:2014 + A11:2021, Laser Class 1, EN 62368-1:2014+A11:2017 2nd Ed., EN IEC 62368-1:2020+A11:2020 Third Edition, UL 62368-1 Third Edition, CAN/CSA C22.2 No. 62368-1-19, CNS 15598-1:2020, EN 55032:2015+A11:2020 Class A, CISPR 32:2015+AMD1:2019 Class A, FCC Part 15 B Class A, VCCI, Directive 2014/35/EU, CISPR 35: 2016, EN 55035:2017+A11:2020, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 6 |
| Width | 21.3 cm |
| Depth | 22.9 cm |
| Height | 4.3 cm |
| Weight | 762 g |
| Service & Support | Limited Warranty - Lifetime |
| Humidity level during use | 5 - 95% RH (non-condensing) |
| Storage humidity level | 5 - 95% RH (non-condensing) |
| Max. operating temperature | 45 °C |
| Max. Storage temperature | 70 °C |
| My. operating temperature | 0 °C |
| My. storage temperature | -40 °C |
