ALLNET ALL-MC109-SFP+ network converter for media 10000 Mbit/s Black
ALLNET ALL-MC109-SFP+. Maximum data transfer rate: 10000 Mbit/s, Incoming converter interface: 10Base-T, 100Base-TX, 1000Base-T, Ethernet interface type: Gigabit Ethernet. Maximum transmission distance: 100 m. LED indicators: Power, Product color: Black. Fiber optic power connector: SFP+, Connection technology: Wired. Output voltage: 5 V, Output current: 2 A, Power consumption (max): 10 W
Availability: In stock
ALLNET ALL-MC109-SFP+. Maximum data transfer rate: 10000 Mbit/s, Incoming converter interface: 10Base-T, 100Base-TX, 1000Base-T, Ethernet interface type: Gigabit Ethernet. Maximum transmission distance: 100 m. LED indicators: Power, Product color: Black. Fiber optic power connector: SFP+, Connection technology: Wired. Output voltage: 5 V, Output current: 2 A, Power consumption (max): 10 W
Specifications
| Maksimal dataoverførselshastighed | 10000 Mbit/s |
| Maksimal overførselsafstand | 100 m |
| Intern | Ingen |
| Fiber optisk strømstik | SFP+ |
| Auto MDI/MDI-X | Ja |
| Auto-forhandling | Ja |
| Duplex system | Fuld |
| Ethernet-grænsefladetype | Gigabit Ethernet |
| Fiber ethernet kabelteknologi | 10GBASE-R, 1000BASE-X |
| Indgående omregner interface | 10Base-T, 100Base-TX, 1000Base-T |
| Kobber ethernet kabelteknologi | 10GBASE-T |
| Understøttede kabeltyper | Cat5, Cat5e, Cat6a |
| LED-indikatorer | Strøm |
| Produktfarve | Sort |
| Ethernet LAN-porte (RJ-45) | 1 |
| Fiberkanal porte | 1 |
| Forbindelsesteknologi | Ledningsført |
| Strømforbrug (maks.) | 10 W |
| Udgangsspænding | 5 V |
| Udgangsstrøm | 2 A |
| Bredde | 71 mm |
| Dybde | 94 mm |
| Højde | 26 mm |
| Vægt | 230 g |
| Driftstemperatur (T-T) | 0 - 50 °C |
| Opbevaringstemperatur (T-T) | -20 - 70 °C |
| Relativ luftfugtighed ved drift (H-H) | 10 - 90% |
| Relativ luftfugtighed ved opbevaring (H-H) | 10 - 90% |
| Certificering | CE |
