Features Ubiquiti UniFi U6-IW

WiFi 6 MU-MIMO 4x4 indoor access point

Transfer speed: 574 Mbps (2.4GHz) and 4800 Mbps (5GHz)

4 Gigabit LAN (1x PoE/PoE+ in and 1x PoE out)

Transmission power: 22 dBm/150mW (2.4GHz), 26 dBm/400 mW (5GHz)

Easy installation via UniFi website or app

Access point with PoE+ support

The UniFi6 IW (In-Wall) is an indoor access point for spreading a wireless WiFi network. This access point has 4 RJ-45 Gigabit Ethernet ports, 1 of which supports PoE output. A prerequisite for this: the U6-IW must itself be connected with PoE+ (802.3at). Otherwise, no PoE output can be provided by the access point. So you can connect an IP device, such as an IP camera or phone, to this access point and provide it with a network connection and power at the same time.

High speed network

This WiFi 6 access point has a maximum throughput speed of 573.5 Mbps on 2.4GHz and a speed of 4.8Gbps on the 5GHz frequency band. The U6-IW also has a transmission power of 22 dBm/150mW (2.4GHz) and 26 dBm/400mW (5GHz).

UniFi controller

The Ubiquiti UniFi In-Wall is managed via the UniFi Controller. With this user-friendly software you can centrally manage multiple access points, but also gain insight into, among other things, the status of the network, the connected devices and the associated network traffic. The UniFi Controller provides a clear overview and is accessible on PC, laptop, tablet and smartphone. This access point is also easy to mount on the wall with the supplied aluminum wall holder. It is important to know that this access point is supplied without a power supply as standard.

Package contents

• Ubiquiti UniFi 6 access point
• Wall bracket
• Mounting material
• Manual
