Broadcom MegaRAID MR216i-p Lagringskontrol
€434,08
HPE MegaRAID 216i-p - Lagringskontrol - 16 Kanal - SATA 6Gb/s / SAS 12Gb/s / PCIe 4.0 (NVMe) - RAID 0, 1, 10 - PCIe 4.0 x8 - for ProLiant DL325 Gen10, DL345 Gen10, DL360 Gen10, DL365 Gen10, DL380 Gen10, DL385 Gen10
Availability: In stock
Secure payment · Fast delivery
EAN:0190017444048Categories:, , Brand:
HPE MegaRAID 216i-p - Lagringskontrol - 16 Kanal - SATA 6Gb/s / SAS 12Gb/s / PCIe 4.0 (NVMe) - RAID 0, 1, 10 - PCIe 4.0 x8 - for ProLiant DL325 Gen10, DL345 Gen10, DL360 Gen10, DL365 Gen10, DL380 Gen10, DL385 Gen10
Specifications
Specifications
| Produktbeskrivelse | HPE MegaRAID 216i-p - lagringskontrol - SATA 6Gb/s / SAS 12Gb/s / PCIe 4.0 (NVMe) - PCIe 4.0 x8 |
| Enhedstype | Lagringskontrol - indstikskort |
| Bustype | PCIe 4.0 x8 |
| Interface | SATA 6Gb/s / SAS 12Gb/s / PCIe 4.0 (NVMe) |
| Buffer størrelse | 4 GB |
| Understøttede enheder | Harddisk |
| Antal kanaler | 16 |
| Maks. antal lagerenheder | 16 |
| RAID-niveau | RAID 0, RAID 1, RAID 10 |
| Systemkrav | SUSE Linux Enterprise Server, Microsoft Windows Server, Red Hat Enterprise Linux, CentOS, Ubuntu, VMware ESXi |
| Dimensioner (B x D x H) | 12.1 cm |
| Vægt | 135 g |
| Producentgaranti | 3 year warranty |
| Designet for | ProLiant DL325 Gen10, DL345 Gen10, DL360 Gen10, DL365 Gen10, DL380 Gen10, DL385 Gen10 |
| Device Type | Storage controller - plug-in card |
| Host Bus | PCIe 4.0 x8 |
| Buffer Size | 4 GB |
| Channel Qty | 16 |
| Max Storage Devices Qty | 16 |
| RAID Level | RAID 0, RAID 1, RAID 10 |
| Supported Devices | Hard drive |
| Connections | 1 x PCIe 4.0 x8 |
| Interfaces | SATA 6Gb/s / SAS 12Gb/s / PCIe 4.0 (NVMe) |
| Features | FastPath |
| OS Required | SUSE Linux Enterprise Server, Microsoft Windows Server, Red Hat Enterprise Linux, CentOS, Ubuntu, VMware ESXi |
| Software Included | StorCLI, HII (UEFI Human Interface Infrastructure), UEFI System Utilities (storage configuration), MegaRAID Storage Administrator, Redfish (Inventory and Events) |
| Service & Support | Limited warranty - parts - 3 years |
| Depth | 12.1 cm |
| Weight | 0.135 kg |
| Designed For | HPE ProLiant DL325 Gen10 Plus V2, DL325 Gen10 Plus V2 Base, DL325 Gen10 Plus V2 Performance, DL345 Gen10 Plus, DL345 Gen10 Plus Base, DL345 Gen10 Plus Entry, DL360 Gen10 Plus, DL360 Gen10 Plus All-NVMe Server for Software Defined Storage, DL360 Gen10 |
| Transfer rate | PCIe Gen4 host / Gen4 NVMe / Gen 3 SAS/SATA |
| Form factor | (MR416i-p Gen10 Plus / MR216i-p Gen10 Plus) – Standard HHHL PCIe plug-in Controller (MR416i-a Gen10 Plus / MR216i-a Gen10 Plus) – Type-a Modular Controller |
| Ports | 2x8 host / x16 internal tri-mode |
| Cache | 4 GB (MR416i-a Gen10 Plus, MR416i-p Gen10 Plus) |
| RAID levels | 0, 1, 10 |
| Additional features | See HPE MR Gen10 Plus Controllers QuickSpecs |
| Servers supported | See HPE MR Gen10 Plus Controllers QuickSpecs for more detail |
| Certifications | See HPE MR Gen10 Plus Controllers QuickSpecs |
| Product dimensions (metric) | 12.1 cm |
