ASRock B650 PG Lightning Bundkort - AMD B650 - AMD AM5 socket - DDR5 RAM - ATX
€113,45
ASRock B650 PG Lightning Bundkort - AMD B650 - AMD AM5 socket - DDR5 RAM - ATX
Availability: In stock
Secure payment · Fast delivery
EAN:4710483940910Categories:, , Brand:
ASRock B650 PG Lightning Bundkort - AMD B650 - AMD AM5 socket - DDR5 RAM - ATX
Specifications
Specifications
| Produktbeskrivelse | ASRock B650 PG Lightning - bundkort - ATX - Socket AM5 - AMD B650 |
| Produkttype | Bundkort - ATX |
| Chipsættype | AMD B650 |
| Processor-socket | 1 x Socket AM5 |
| Kompatible processorer | Ryzen (understøtter Ryzen 7000 Series) |
| Max RAM-størrelse | 128 GB |
| RAM understøttet | 4 DIMM slots - DDR5, non-ECC, not buffered |
| Lagringsporte | 4 x SATA-600 (RAID), 1 x M.2, 1 x Hyper M.2, 1 x Blazing M.2 |
| USB / FireWire porte | 1 x USB-C 3.2 Gen 2x2 + 7 x USB 3.2 Gen 1 + 4 x USB 2.0 + (1 x USB-C 3.2 Gen 2 + 2 x USB 3.2 Gen 1 + 4 x USB 2.0 via samlekasser) |
| Audio | HD Audio (8-kanaler) |
| LAN | 2.5 Gigabit Ethernet |
| Chipset Type | AMD B650 |
| Compatible Processors | Ryzen (supports Ryzen 7000 Series) |
| Max Processors Qty | 1 |
| Processor Socket | Socket AM5 |
| Product Type | Motherboard - ATX |
| Bus Clock | 6400 MHz (O.C.) |
| Features | Dual channel memory architecture, Intel Extreme Memory Profiles (XMP), AMD EXPO technology |
| Max Size | 128 GB |
| Registered or Buffered | Unbuffered |
| Supported RAM Integrity Check | Non-ECC |
| Technology | DDR5 |
| Audio Codec | Realtek ALC897 |
| Compliant Standards | FCC, EuP Ready, ErP Ready, HDCP 2.3 |
| Type | HD Audio (8-channel) |
| Network Controller | Dragon RTL8125BG |
| Network Interfaces | 2.5 Gigabit Ethernet |
| Expansion Slots | 1 x CPU | 4 x DIMM 288-pin | 1 x PCIe 4.0 x16 | 1 x PCIe 4.0 x16 (x2 mode) | 2 x PCIe 4.0 x1 | 1 x M.2 socket (2230 M.2 Key E slot) | 3 x M.2 socket (2280 M.2 Key M slot) |
| Interfaces | 1 x USB-C 3.2 Gen2x2 | 7 x USB 3.2 Gen 1 | 1 x LAN (2.5Gigabit Ethernet) | 4 x USB 2.0 | 1 x HDMI | 1 x audio line-in - mini-jack | 1 x microphone - mini-jack | 1 x audio line-out (front surround) - mini-jack |
| Internal Interfaces | 1 x USB-C 3.2 Gen 2 - header | 2 x USB 3.2 Gen 1 - header | 4 x USB 2.0 - header | 1 x SPI - header | 1 x audio - header | 1 x speaker - header |
| Power Connectors | 24-pin main power connector, 2 x 8-pin ATX12V connectors |
| Storage Interfaces | SATA-600 -connectors: 4 x 7pin Serial ATA - RAID 0 / RAID 1 / RAID 10 | PCIe 5.0 -connectors: 1 x M.2 - RAID 0 / RAID 1 / RAID 10 | PCIe 4.0 -connectors: 2 x M.2 - RAID 0 / RAID 1 / RAID 10 |
| BIOS Features | UEFI BIOS |
| BIOS Type | AMI |
| Hardware Features | ASRock Instant Flash, 15µ Gold Contact, 8 Layer PCB, ASRock Full HD UEFI, Water Pump Header, pre-mounted I/O shield, ASRock POST Status Checker (PSC), ASRock Auto Driver Installer, 60A Smart Power Stage, BIOS FlashBack button, 14+2+1 Phase Power Desi |
| Cables Included | 2 x Serial ATA cable |
| Depth | 24.4 cm |
| Included Accessories | 3 x M.2 screws |
| Software Included | ASRock Phantom Gaming Tuning, ASRock Phantom Gaming LAN Software, ASRock Polychrome SYNC |
| Width | 30.5 cm |
