Number of hot-swap bays: 8 Embedded Security: Trusted Platform Module (TPM 2.0) Security Chip Localization: Region: Europe Product model: Rack-mountable - 2U Server scalability: 2-way Type: Server Number of CPUs: 1 Number of cores: 16-core Chipset type: Intel C741 Clock frequency: 2 GHz CPU: Intel Xeon Silver 4514Y Max. number of CPUs: 2 Max Turbo Speed: 3.4 GHz Upgradability of CPU: Upgradable Cache per processor: 30 MB Installed size: L3 - 30 MB Effective memory speed: 2800 MHz Features: Registered, HPE SmartMemory, slots 17 - 32 are only available in dual processor configuration Holders: 32 (Total) / 28 (unused) Installed size: 128 GB (installed) / 8 TB (max) Configuration features: 4 x 32 GB Model: DIMM 288-PIN Technology: DDR5 SDRAM Rated memory speed: 2800 MHz Type: No HDD Controller Interface Type: NVM Express Storage controller name: HPE NS204i-u Type: 1 Type: No optical drive Monitor Type: None. Video interfaces: VGA Video memory: 16 MB Data connection protocol: 10 Gigabit Ethernet Features: Wake on LAN (WoL), PXE support Ethernet Controller: Broadcom BCM57416 Ethernet Ports: 2 x 10 Gigabit Ethernet Remote Management Controller: Integrated Lights-Out 6 Bays: 1 (total) / 1 (free) x external Universal Media Bay | 8 (total) / 8 (free) x hot-swap 2.5" SFF Holders: 2 (total) / 2 (free) x FlexibleLOM | 1 (total) / 1 (free) x PCIe 5.0 x16 - full length, full height | 1 (total) / 1 (free) x PCIe 5.0 x16 - full length, full height (x8 mode) | 1 (total) / 1 (free) x PCIe 5.0 x16 - half length, full height (x8 mode) Interface: 1 x USB 3.0 (1 front) (HPE iLO Service Port) | 4 x USB 3.0 (2 rear, 2 internal) | 1 x HPE iLO - RJ-45 (1 rear) | 1 x VGA (1 rear) | 2 x LAN (10Gigabit Ethernet) Manufacturer Seller Program: HPE Smart Choice Compliance Standards: AES, FIPS 140-2, Triple DES, TLS v1.2, Low Halogen, ASHRAE Class A4, ASHRAE Class A3, WEEE 2002/95/EC, Redfish API, ACPI 6.3, SMBIOS 3.2, ErP Lot 9 Equipment included: 6 high performance fans 80 PLUS certification: 80 PLUS Titanium Number installed: 2 Device type: Power supply - hot-plug Max. number supported: 2 Required voltage: AC 100-240 V Excess voltage: Yes Scheme for excess voltage: 1+1 Power supply: 1000 watts With OS: No operating system OS Certified: Microsoft Windows Server, Red Hat Enterprise Linux, VMware ESXi, Oracle Linux, Canonical Ubuntu, Citrix Software: HPE Server UEFI ENERGY STAR certified: Yes Service & Support: Limited warranty - parts and labor - 3 years - on-site Width: 44.8 cm Depth: 72.7 cm Height: 8.75 cm Weight: 16 kg Humidity in use: 8 - 90% RH (non-condensing) Max. operating temperature: 35 °C Min. operating temperature: 10 °C
