Number of hot-swap bays: 8 Embedded Security: Trusted Platform Module (TPM) Security Chip Built-in equipment: LED panel Localization: Region: EMEA Product model: Rack-mountable - 2U Server scalability: 2-way Type: Server Number of CPUs: 1 Number of cores: 8-core Chipset type: Intel C741 Clock frequency: 2.6 GHz CPU: Intel Xeon Silver 4509Y Max. number of CPUs: 2 Max Turbo Speed: 4.1 GHz Upgradability of CPU: Upgradable Cache per processor: 22.5 MB Installed size: 22.5 MB Effective memory speed: 4400 MHz Features: Registered, HPE SmartMemory, slots 17 - 32 are only available in dual processor configuration Holders: 32 (Total) / 31 (unused) Installed Size: 32 GB (Installed) / 8 TB (Max) Configuration features: 1 x 32 GB Model: DIMM 288-PIN Technology: DDR5 SDRAM Rated memory speed: 5600 MHz Type: No HDD Number of channels: 8 Buffer size: 4 GB Controller interface type: Serial ATA-600 / SAS 3.0 / PCI Express (NVMe) RAID level: RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, RAID 60 Storage controller name: HPE MR408i-o Gen11 SPDM Type: 1 x RAID - OCP Type: No optical drive Monitor Type: None. Video interfaces: VGA Video memory: 16 MB Data connection protocol: Ethernet, Fast Ethernet, Gigabit Ethernet Features: Wake on LAN (WoL), PXE support Ethernet Controller: Broadcom BCM5719 Ethernet Ports: 4 x Gigabit Ethernet Interface (bus) type: Open Compute Project mezzanine (OCP) 3.0 Protocol for remote management: SNMP 3, IPMI 2.0, SMASH CLP Remote Management Controller: Integrated Lights-Out 6 Bays: 1 (total) / 1 (free) x external Universal Media Bay | 8 (total) / 8 (free) x hot-swap 2.5" SFF Holders: 2 (total) / 2 (free) x FlexibleLOM | 1 (total) / 1 (free) x PCIe 5.0 x16 - full length, full height | 1 (total) / 1 (free) x PCIe 5.0 x16 - full length, full height (x8 mode) | 1 (total) / 1 (free) x PCIe 5.0 x16 - half length, full height (x8 mode) Interface: 1 x USB 3.2 Gen 1 (1 front) | 4 x USB 3.0 (2 rear, 2 internal) | 1 x HPE iLO (1 rear) | 1 x VGA (1 rear) | 4 x LAN (Gigabit Ethernet) Compliance Standards: AES, FIPS 140-2, Triple DES, TLS v1.2, Low Halogen, ASHRAE Class A4, ASHRAE Class A3, WEEE 2002/95/EC, Redfish API, ACPI 6.3, SMBIOS 3.2, ErP Lot 9 Equipment included: HPE Easy Install Rails 80 PLUS certification: 80 PLUS Titanium Number installed: 1 Device type: Power supply - hot-plug Max. number supported: 2 Required voltage: AC 100-240 V Excess voltage: Yes Scheme for excess voltage: 1+1 (with optional power supply unit) Power supply: 1000 watts With OS: No operating system OS Certified: SUSE Linux Enterprise Server, Microsoft Windows Server, Red Hat Enterprise Linux, VMware ESXi, Oracle Linux, Canonical Ubuntu, Oracle VM ENERGY STAR version: 3.0 ENERGY STAR certified: Yes Service & Support: Limited warranty - parts and labor - 3 years - on-site - response time: next business day Width: 44.8 cm Depth: 72.7 cm Height: 8.75 cm Humidity in use: 8 - 90% RH (non-condensing) Max. operating temperature: 35 °C Min. operating temperature: 10 °C
