ALLDAQ ADQ-42 V1.5 / programmable current sink with 2 potential-free channels / continuous power 15W / resolution 1mA (16bit DAC)
This module from ALLDAQ's series of multi-channel current sinks is ideal for generating different loads individually isolated in a small space
Availability: In stock
["This module from ALLDAQ's series of multi-channel current sinks is ideal for generating different loads individually isolated in a small space", "Module with 2 individually isolated current sinks", "Controllable via I²C or analog (via potentiometer or external control voltage)", "Address configuration via a rotary switch", "Continuous power 20W", "Peak power 100W", "Resolution 1mA (16 bit DAC)", "Up to 36V source voltage", "12V supply voltage", "Measurement of current and voltage (16 bit ADC) per channel", "Sense line for monitoring the source voltage", "Up to 40° ambient temperature (passively cooled)", "Temperature emergency shutdown with signal LED (readable via I²C)", "All plugs locked", "Cascadable up to 8 boards per I²C bus"]
Specifications
| Feature 1 | Dieses Modul aus der Serie an Multi-Kanal Stromsenken von ALLDAQ eignet sich ideal um unterschiedliche Lasten auf engstem Raum individuell isoliert zu generieren |
| Feature 2 | Module with 2 individually isolated current sinks |
| Feature 3 | Controllable via I²C or analog (via potentiometer or external control voltage) |
| Feature 4 | Address configuration via a rotary switch |
| Feature 5 | Continuous power 20W |
| Feature 6 | Peak power 100W |
| Feature 7 | Resolution 1mA (16 bit DAC) |
| Feature 8 | Up to 36V source voltage |
| Feature 9 | 12V supply voltage |
| Feature 10 | Measurement of current and voltage (16 bit ADC) per channel |
| Feature 11 | Sense line for monitoring the source voltage |
| Feature 12 | Up to 40° ambient temperature (passively cooled) |
| Feature 13 | Temperature emergency shutdown with signal LED (readable via I²C) |
| Feature 14 | Alle Stecker arretiert |
| Feature 15 | Kaskadierbar bis zu 8 Boards pro I²C-Bus |
