Elo Touch Solutions 7'', 16:9, 1280 x 800, 16:10, 40 ms, HDMI
This Item: Elo 0764L 7-inch HD Optically bonded LCD (LED Backlight), Open Frame, Projected Capacitive 10 Touch, Zero-Bezel, USB-C, HDMI & Display Port video interface, USB-C touch, Clear, No power brick _____________________________________________ Elo's 0764L 7-inch HD open-frame delivers a brilliant, industrial-grade touchscreen monitor designed for easy integration into enclosures. With sleek, narrow borders and a modern form factor, the 0764L is well-suited for industrial controls, HMI, warehouse automation, gaming and more.
Availability: In stock
This Item: Elo 0764L 7-inch HD Optically bonded LCD (LED Backlight), Open Frame, Projected Capacitive 10 Touch, Zero-Bezel, USB-C, HDMI & Display Port video interface, USB-C touch, Clear, No power brick _____________________________________________ Elo's 0764L 7-inch HD open-frame delivers a brilliant, industrial-grade touchscreen monitor designed for easy integration into enclosures. With sleek, narrow borders and a modern form factor, the 0764L is well-suited for industrial controls, HMI, warehouse automation, gaming and more.
Specifications
| Built-in speaker(s) | No |
| Discrete graphics card model | Not available |
| Internal memory | 4 GB |
| On-board graphics card model | Intel® UHD Graphics 610 |
| Processor frequency | 2,9 GHz |
| Processor manufacturer | Intel |
| Processor model | G4900T |
| Anti-glare screen | Yes |
| Orientation | Horizontal/Vertical |
| Panel mounting interface | 75 x 75 mm |
| Placement supported | Indoor |
| Product colour | Black |
| Product design | Digital signage flat panel |
| Screen shape | Flat |
| VESA mounting | Yes |
| Active display area (W x H) | 149.76 x 93.6 mm |
| Contrast ratio (typical) | 800:1 |
| Display brightness | 400 cd/m² |
| Display diagonal | 7 " |
| Display resolution | 1280 x 800 pixels |
| Display technology | LED |
| LED backlight | Yes |
| Multi-touch | Yes |
| Native aspect ratio | 16:9 |
| Number of displays | 1 |
| Number of simultaneous touchpoints | 10 |
| Panel type | TFT-LCD |
| Response time | 40 ms |
| Touchscreen | Yes |
| Touchscreen technology | Projected capacitive system |
| Viewing angle, horizontal | 176 ° |
| Viewing angle, vertical | 176 ° |
| Quantity per pack | 1 pc(s) |
| Ethernet LAN | No |
| Operating relative humidity (H-H) | 20 - 80 % |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage relative humidity (H-H) | 10 - 95 % |
| Storage temperature (T-T) | -20 - 60 °C |
| Aspect ratio | 16:10 |
| Mean time between failures (MTBF) | 50000 h |
| Number of OSD languages | 8 |
| On Screen Display (OSD) | Yes |
| On Screen Display (OSD) languages | English, French, German, Italian, Japanese, Simplified Chinese, Spanish, Traditional Chinese |
| DisplayPorts quantity | 1 |
| HDMI ports quantity | 1 |
| USB connector type | USB Type-C |
| USB port | Yes |
| USB ports quantity | 1 |
| AC input frequency | 50 - 60 Hz |
| AC input voltage | 100 - 240 V |
| Energy consumption (SDR) per 1000 hours | 8 kWh |
| Energy efficiency class (SDR) | D |
| Energy efficiency scale | A to G |
| Power consumption (off) | 0,15 W |
| Power consumption (sleep) | 0,8 W |
| Power consumption (typical) | 8 W |
| Compliance certificates | CB, CCC, CE, China Compulsory Certification (CCC), Federal Communications Commission (FCC), Norma Oficial Mexicana (NOM), UKCA, VCCI |
| Brand Name | Elo Touch Solutions |
| Warranty | 3 years |
| Display depth | 3,17 cm |
| Display height | 12 cm |
| Display weight | 660 g |
| Display width | 17,62 cm |
