XEON E-2244G 3.8GHz Tray CPU
€458,34
XEON E-2244G 3.8GHz Tray CPU
Availability: In stock
Secure payment · Fast delivery
EAN:W129333629Categories:, , Brand:
XEON E-2244G 3.8GHz Tray CPU
Specifications
Specifications
| Commodity Classification Automated Tracking System (CCATS) | G077159 |
| CPU configuration (max) | 1 |
| Embedded options available | No |
| Execute Disable Bit | Yes |
| Export Control Classification Number (ECCN) | 5A992C |
| Idle States | Yes |
| Market segment | Server |
| Maximum number of PCI Express lanes | 16 |
| PCI Express CEM revision | 3.0 |
| PCI Express configurations | 1x16, 1x8+2x4, 2x8 |
| PCI Express slots version | 3.0 |
| Scalability | 1S |
| Supported instruction sets | AVX 2.0, SSE4.1, SSE4.2 |
| Thermal Monitoring Technologies | Yes |
| Discrete graphics card | No |
| Discrete graphics card model | Not available |
| Maximum on-board graphics card memory | 128 GB |
| Number of displays supported (on-board graphics) | 3 |
| On-board graphics card | Yes |
| On-board graphics card 4K support | Yes |
| On-board graphics card base frequency | 350 MHz |
| On-board graphics card DirectX version | 12.0 |
| On-board graphics card dynamic frequency (max) | 1200 MHz |
| On-board graphics card maximum resolution (DisplayPort) | 4096 x 2304 pixels |
| On-board graphics card maximum resolution (eDP - Integrated Flat Panel) | 4096 x 2304 pixels |
| On-board graphics card maximum resolution (HDMI) | 4096 x 2160 pixels |
| On-board graphics card model | Intel UHD Graphics P630 |
| On-board graphics card OpenGL version | 4.5 |
| On-board graphics card refresh rate at maximum resolution (DisplayPort) | 60 Hz |
| On-board graphics card refresh rate at maximum resolution (HDMI) | 24 Hz |
| ECC | Yes |
| Maximum internal memory supported by processor | 128 GB |
| Memory channels | Dual-channel |
| Memory clock speeds supported by processor | 2666 MHz |
| Memory types supported by processor | DDR4-SDRAM |
| Operational conditions | Tcase 69,3 °CTjunction 100 °C |
| Tcase 69,3 °C | Tjunction 100 °C |
| Tcase | 69,3 °C |
| Tjunction | 100 °C |
| Other features | Maximum internal memory 128 GB |
| Maximum internal memory | 128 GB |
| Box | No |
| Component for | Server/workstation |
| Cooler included | No |
| Package type | Tray |
| Processor ARK ID | 191041 |
| Processor base frequency | 3,8 GHz |
| Processor boost frequency | 4,8 GHz |
| Processor cache | 8 MB |
| Processor cache type | Smart Cache |
| Processor codename | Coffee Lake |
| Processor cores | 4 |
| Processor family | Intel Xeon E |
| Processor lithography | 14 nm |
| Processor manufacturer | Intel |
| Processor model | E-2244G |
| Processor operating modes | 64-bit |
| Processor socket | LGA 1151 (Socket H4) |
| Processor threads | 8 |
| System bus rate | 8 GT/s |
| Thermal Design Power (TDP) | 71 W |
| Enhanced Intel SpeedStep Technology | Yes |
| Intel 64 | Yes |
| Intel Clear Video Technology | Yes |
| Intel Software Guard Extensions (Intel SGX) | Yes |
| Intel Trusted Execution Technology | Yes |
| Intel TSX-NI | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel® Boot Guard | Yes |
| Intel® Clear Video HD Technology (Intel® CVT HD) | Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel® InTru™ 3D Technology | Yes |
| Intel® Memory Protection Extensions (Intel® MPX) | Yes |
| Intel® Optane™ Memory Ready | Yes |
| Intel® OS Guard | Yes |
| Intel® Quick Sync Video Technology | Yes |
| Intel® Secure Key | Yes |
| Intel® Transactional Synchronization Extensions | Yes |
| Intel® Turbo Boost Technology | 2.0 |
| Intel® Turbo Boost Technology 2.0 frequency | 4,8 GHz |
| Intel® vPro™ Platform Eligibility | Yes |
| Bus speed | 8 GT/s |
| Launch date | Q2'19 |
| Maximum graphics card memory | 128 GB |
| Maximum memory | 128 GB |
| Maximum resolution & refresh rate (DisplayPort) | 4096x2304@60Hz |
| Processor ID | 0x3E96 |
| Product type | Processor |
| Servicing status | Baseline Servicing |
| Status | Launched |
| Supported memory types | DDR4-SDRAM |
| Vendor information | Brand Name Intel Warranty 1 År |
| Brand Name Intel | Warranty 1 År |
| Brand Name | Intel |
| Warranty | 1 År |
| Weight & dimensions | Processor package size 37.5mm x 37.5mm mm |
| Processor package size | 37.5mm x 37.5mm mm |
| Hovedkategori | Server, Computer & Printer Parts |
| Underkategori | CPUs |
