Lenovo Intel Xeon Gold 5115, f/ Lenovo ThinkSystem SR850
The SR850 supports Gold and Platinum level processors in the Intel Xeon Processor Scalable Family. The server supports two or four processors. - Processors 1 and 2 are installed in sockets on the system board. - Processors 3 and 4 are installed on the Processor and Memory Expansion Tray. The SR850 Processor and Memory Expansion Tray has a patent-pending sliding and rolling lift mechanism that requires only a one-handed operation to insert or remove from the server. It has a toolless design for superior usability, serviceability and reliability.
Availability: In stock
The SR850 supports Gold and Platinum level processors in the Intel Xeon Processor Scalable Family. The SR850 supports Gold and Platinum level processors in the Intel Xeon Processor Scalable Family. The server supports two or four processors. - Processors 1 and 2 are installed in sockets on the system board. - Processors 3 and 4 are installed on the Processor and Memory Expansion Tray. The SR850 Processor and Memory Expansion Tray has a patent-pending sliding and rolling lift mechanism that requires only a one-handed operation to insert or remove from the server. It has a toolless design for superior usability, serviceability and reliability.
Specifications
| Embedded options available | No |
| Market segment | Server |
| Maximum number of PCI Express lanes | 48 |
| PCI Express slots version | 3.0 |
| Scalability | S4S |
| On-board graphics card | No |
| ECC | Yes |
| Maximum internal memory supported by processor | 768 GB |
| Memory channels | Hexa-channel |
| Memory clock speeds supported by processor | 2400 MHz |
| Memory types supported by processor | DDR4-SDRAM |
| Tcase | 76 °C |
| Compatibility | Lenovo ThinkSystem SR850 |
| Component for | Server/workstation |
| Processor base frequency | 2,4 GHz |
| Processor boost frequency | 3,2 GHz |
| Processor cache | 13,75 MB |
| Processor cache type | L3 |
| Processor codename | Skylake |
| Processor cores | 10 |
| Processor family | Intel® Xeon® Gold |
| Processor generation | 1st Generation Intel® Xeon® Scalable |
| Processor lithography | 14 nm |
| Processor model | 5115 |
| Processor operating modes | 64-bit |
| Processor socket | LGA 3647 (Socket P) |
| Processor threads | 20 |
| Thermal Design Power (TDP) | 85 W |
| Conflict-Free processor | Yes |
| Intel 64 | Yes |
| Intel Trusted Execution Technology | Yes |
| Intel TSX-IN | Yes |
| Intel Turbo Boost Max Technology 3.0 | No |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel® Optane™ Memory Ready | No |
| Intel® Speed Shift Technology | Yes |
| Intel® Turbo Boost Technology | 2.0 |
| Intel® vPro™ Platform Eligibility | Yes |
| Brand Name | Lenovo |
| Warranty | 1 year |
| Processor package size | 76 x 56.5 mm |
