Pentium Gold G5400 processor
€49,67
Pentium Gold G5400 processor
Availability: In stock
Secure payment · Fast delivery
EAN:W129047962Categories:, , Brand:
Pentium Gold G5400 processor
Specifications
Specifications
| Commodity Classification Automated Tracking System (CCATS) | G077159 |
| CPU configuration (max) | 1 |
| Embedded options available | Yes |
| Execute Disable Bit | Yes |
| Export Control Classification Number (ECCN) | 5A992.C |
| Idle States | Yes |
| Market segment | Desktop |
| Maximum number of PCI Express lanes | 16 |
| PCI Express CEM revision | 3.0 |
| PCI Express configurations | 1x16, 1x8+2x4, 2x8 |
| PCI Express slots version | 3.0 |
| Scalability | 1S |
| Supported instruction sets | SSE4.1, SSE4.2 |
| Thermal Monitoring Technologies | Yes |
| Thermal solution specification | PCG 2015C |
| Use conditions | Embedded Broad Market Commercial Temp, PC/Client/Tablet |
| Discrete graphics card | No |
| Discrete graphics card model | Not available |
| Maximum on-board graphics card memory | 64 GB |
| Number of displays supported (on-board graphics) | 3 |
| On-board graphics card | Yes |
| On-board graphics card 4K support | Yes |
| On-board graphics card base frequency | 350 MHz |
| On-board graphics card DirectX version | 12.0 |
| On-board graphics card dynamic frequency (max) | 1,05 MHz |
| On-board graphics card maximum resolution (DisplayPort) | 4096 x 2304 pixels |
| On-board graphics card maximum resolution (eDP - Integrated Flat Panel) | 4096 x 2304 pixels |
| On-board graphics card maximum resolution (HDMI) | 4096 x 2304 pixels |
| On-board graphics card model | Intel® UHD Graphics 610 |
| On-board graphics card OpenGL version | 4.5 |
| On-board graphics card refresh rate at maximum resolution (DisplayPort) | 60 Hz |
| On-board graphics card refresh rate at maximum resolution (HDMI) | 24 Hz |
| ECC | Yes |
| Maximum internal memory supported by processor | 64 GB |
| Memory channels | Dual-channel |
| Memory clock speeds supported by processor | 2400 MHz |
| Memory types supported by processor | DDR4-SDRAM |
| Operational conditions | Tjunction 100 °C |
| Tjunction | 100 °C |
| Other features | Maximum internal memory 65536 MBMaximum internal memory 64 GB |
| Maximum internal memory 65536 MB | Maximum internal memory 64 GB |
| Maximum internal memory | 64 GB |
| Box | No |
| Bus type | DMI3 |
| Component for | PC |
| Cooler included | No |
| Memory bandwidth supported by processor (max) | 37,5 GB/s |
| Package type | Tray |
| Processor ARK ID | 129951 |
| Processor base frequency | 3,7 GHz |
| Processor cache | 4096 KB |
| Processor cache type | Smart Cache |
| Processor codename | Coffee Lake |
| Processor cores | 2 |
| Processor family | Intel® Pentium® Gold |
| Processor lithography | 14 nm |
| Processor manufacturer | Intel |
| Processor model | G5400 |
| Processor operating modes | 64-bit |
| Processor series | Intel Pentium Gold Series |
| Processor socket | LGA 1151 (Socket H4) |
| Processor threads | 4 |
| System bus rate | 8 GT/s |
| Thermal Design Power (TDP) | 58 W |
| Enhanced Intel SpeedStep Technology | Yes |
| Intel 64 | Yes |
| Intel Clear Video Technology | Yes |
| Intel Enhanced Halt State | Yes |
| Intel Identity Protection Technology version | 1.00 |
| Intel Secure Key Technology version | 1.00 |
| Intel Software Guard Extensions (Intel SGX) | Yes |
| Intel Stable Image Platform Program (SIPP) | No |
| Intel Stable Image Platform Program (SIPP) version | 0 |
| Intel Trusted Execution Technology | No |
| Intel TSX-NI | No |
| Intel TSX-NI version | 0.00 |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel® Boot Guard | Yes |
| Intel® Clear Video HD Technology (Intel® CVT HD) | Yes |
| Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID) | Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel® Identity Protection Technology (Intel® IPT) | Yes |
| Intel® InTru™ 3D Technology | Yes |
| Intel® Memory Protection Extensions (Intel® MPX) | Yes |
| Intel® Optane™ Memory Ready | Yes |
| Intel® OS Guard | Yes |
| Intel® Quick Sync Video Technology | Yes |
| Intel® Secure Key | Yes |
| Intel® Stable IT Platform Program (SIPP) | No |
| Intel® Transactional Synchronization Extensions | No |
| Intel® Turbo Boost Technology | No |
| Intel® vPro™ Platform Eligibility | No |
| Bus bandwidth | 8 |
| Bus speed | 8 GT/s |
| Bus type units | GT/s |
| End of servicing updates date | Monday, June 30, 2025 |
| Last change | 63903513 |
| Launch date | Q2'18 |
| Maximum graphics card memory | 64 GB |
| Maximum memory | 64 GB |
| Maximum resolution & refresh rate (DisplayPort) | 4096x2304@60Hz |
| Maximum resolution & refresh rate (HDMI) | 4096x2304@24Hz |
| Maximum resolution & refresh rate (Integrated Flat Panel) | 4096x2304@60Hz |
| OpenGL support | Yes |
| Processor brand name | Intel Pentium Gold (2017), Intel Pentium Gold Processor (2017) |
| Processor ID | 0x3E90/x93 |
| Product family | Intel Pentium Processor |
| Product type | Processor |
| Status | Launched |
| Supported memory types | DDR4-SDRAM |
| Vendor information | Brand Name Intel Warranty 3 År |
| Brand Name Intel | Warranty 3 År |
| Brand Name | Intel |
| Warranty | 3 År |
| Weight & dimensions | Processor package size 37.5 x 37.5 mm |
| Processor package size | 37.5 x 37.5 mm |
| Hovedkategori | Server, Computer & Printer Parts |
| Underkategori | CPUs |
