Dell 2x Intel Xeon E7-4809 v4, 8-core, 2.1 GHz, 20 MB Cache, 6.4 GT/s QPI, 115 W, Intel 64
The Intel® E7-4809 v4 2.1GHz Processor enhance the performance and the speed of your system. Additionally, the Virtualization Technology enables migration of more environments. It supports enhanced Speedstep® technology that allows tradeoffs to be made between performance and power consumption. Its Thermal Monitoring Technologies protect the processor package and the system from thermal failure through several thermal management features. The VT-x with Extended Page Tables (EPT) also known as Second Level Address Translation (SLAT), provides acceleration for memory intensive virtualized applications. Packed with more features, the E7-4809 v4 2.1GHz Processor is the ideal choice for virtually all of your data demanding or standard enterprise infrastructure applications.
Availability: In stock
The Intel® E7-4809 v4 2.1GHz Processor enhance the performance and the speed of your system. Additionally, the Virtualization Technology enables migration of more environments. It supports enhanced Speedstep® technology that allows tradeoffs to be made between performance and power consumption. Its Thermal Monitoring Technologies protect the processor package and the system from thermal failure through several thermal management features. The VT-x with Extended Page Tables (EPT) also known as Second Level Address Translation (SLAT), provides acceleration for memory intensive virtualized applications. Packed with more features, the E7-4809 v4 2.1GHz Processor is the ideal choice for virtually all of your data demanding or standard enterprise infrastructure applications.
Specifications
| CPU configuration (max) | 4 |
| Embedded options available | No |
| Execute Disable Bit | Yes |
| Idle States | Yes |
| Market segment | Server |
| Maximum number of PCI Express lanes | 32 |
| PCI Express slots version | 3.0 |
| Physical Address Extension (PAE) | 46 bit |
| Scalability | S4S |
| Supported instruction sets | AVX 2.0 |
| Thermal Monitoring Technologies | Yes |
| Discrete graphics card | No |
| Discrete graphics card model | Not available |
| On-board graphics card | No |
| On-board graphics card model | Not available |
| ECC | Yes |
| Maximum internal memory supported by processor | 3 TB |
| Memory channels | Quad-channel |
| Memory clock speeds supported by processor | 1066, 1333, 1600, 1866 |
| Memory types supported by processor | DDR3-SDRAM, DDR4-SDRAM |
| Tcase | 69 °C |
| Compatibility | - PowerEdge R930 |
| Bus type | QPI |
| Component for | Server/workstation |
| Memory bandwidth supported by processor (max) | 102 GB/s |
| Number of QPI links | 3 |
| Processor base frequency | 2,1 GHz |
| Processor cache | 20 MB |
| Processor cache type | L3 |
| Processor cores | 8 |
| Processor family | Intel Xeon E7 v4 |
| Processor lithography | 14 nm |
| Processor model | E7-4809V4 |
| Processor operating modes | 64-bit |
| Processor series | Intel Xeon E7-4800 v4 |
| Processor socket | LGA 2011 (Socket R) |
| Processor threads | 16 |
| Stepping | B0 |
| System bus rate | 6,4 GT/s |
| Thermal Design Power (TDP) | 115 W |
| Enhanced Intel SpeedStep Technology | Yes |
| Intel 64 | Yes |
| Intel Instruction Replay Technology | No |
| Intel Trusted Execution Technology | Yes |
| Intel TSX-IN | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel® OS Guard | Yes |
| Intel® Secure Key | Yes |
| Intel® Turbo Boost Technology | No |
| Brand Name | Dell |
| Warranty | 1 year |
