E3-1225v6
€294,87
E3-1225v6
Availability: In stock
Secure payment · Fast delivery
EAN:W129334007Categories:, , Brand:
E3-1225v6
Specifications
Specifications
| Commodity Classification Automated Tracking System (CCATS) | G077159 |
| CPU configuration (max) | 1 |
| Embedded options available | No |
| Execute Disable Bit | Yes |
| Export Control Classification Number (ECCN) | 5A992C |
| Idle States | Yes |
| Market segment | Server |
| Maximum number of PCI Express lanes | 16 |
| PCI Express CEM revision | 3.0 |
| PCI Express configurations | 1x16, 1x8+2x4, 2x8 |
| PCI Express slots version | 3.0 |
| Scalability | 1S |
| Supported instruction sets | AVX 2.0, SSE4.1, SSE4.2 |
| Thermal Monitoring Technologies | Yes |
| Discrete graphics card | No |
| Discrete graphics card model | Not available |
| Maximum on-board graphics card memory | 64 GB |
| Number of displays supported (on-board graphics) | 3 |
| On-board graphics card | Yes |
| On-board graphics card 4K support | Yes |
| On-board graphics card base frequency | 350 MHz |
| On-board graphics card DirectX version | 12.0 |
| On-board graphics card dynamic frequency (max) | 1150 MHz |
| On-board graphics card maximum resolution (DisplayPort) | 4096 x 2304 pixels |
| On-board graphics card maximum resolution (eDP - Integrated Flat Panel) | 4096 x 2304 pixels |
| On-board graphics card maximum resolution (HDMI) | 4096 x 2160 pixels |
| On-board graphics card model | Intel® HD Graphics P630 |
| On-board graphics card OpenGL version | 4.4 |
| On-board graphics card outputs supported | DisplayPort, DVI, Embedded DisplayPort (eDP), HDMI |
| On-board graphics card refresh rate at maximum resolution (DisplayPort) | 60 Hz |
| On-board graphics card refresh rate at maximum resolution (HDMI) | 24 Hz |
| ECC | Yes |
| Maximum internal memory supported by processor | 64 GB |
| Memory channels | Dual-channel |
| Memory clock speeds supported by processor | 1866, 2400 |
| Memory types supported by processor | DDR3L-SDRAM, DDR4-SDRAM |
| Other features | Graphics output eDP/DP/HDMI/DVI Maximum internal memory 65536 MBMaximum internal memory 64 GBVideo decoding Yes |
| Graphics output | eDP/DP/HDMI/DVI |
| Maximum internal memory | 64 GB |
| Video decoding | Yes |
| Box | Yes |
| Bus type | DMI3 |
| Component for | Server/workstation |
| Cooler included | Yes |
| Memory bandwidth supported by processor (max) | 37,5 GB/s |
| Package type | Box |
| Processor ARK ID | 97476 |
| Processor base frequency | 3,3 GHz |
| Processor boost frequency | 3,7 GHz |
| Processor cache | 8192 KB |
| Processor cache type | Smart Cache |
| Processor codename | Kaby Lake |
| Processor cores | 4 |
| Processor family | Intel® Xeon® E3 v6 |
| Processor lithography | 14 nm |
| Processor manufacturer | Intel |
| Processor model | E3-1225 v6 |
| Processor operating modes | 64-bit |
| Processor socket | LGA 1151 (Socket H4) |
| Processor threads | 4 |
| System bus rate | 8 GT/s |
| Thermal Design Power (TDP) | 73 W |
| VID Voltage Range | 0.55 - 1.52 V |
| Conflict-Free processor | Yes |
| Enhanced Intel SpeedStep Technology | Yes |
| Intel 64 | Yes |
| Intel Clear Video Technology | Yes |
| Intel Enhanced Halt State | Yes |
| Intel Secure Key Technology version | 1.00 |
| Intel Software Guard Extensions (Intel SGX) | Yes |
| Intel Trusted Execution Technology | Yes |
| Intel TSX-NI | Yes |
| Intel TSX-NI version | 1.00 |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel® Boot Guard | Yes |
| Intel® Clear Video HD Technology (Intel® CVT HD) | Yes |
| Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID) | Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) | No |
| Intel® InTru™ 3D Technology | Yes |
| Intel® Memory Protection Extensions (Intel® MPX) | Yes |
| Intel® Optane™ Memory Ready | Yes |
| Intel® OS Guard | Yes |
| Intel® Quick Sync Video Technology | Yes |
| Intel® Secure Key | Yes |
| Intel® Transactional Synchronization Extensions | Yes |
| Intel® Turbo Boost Technology | 2.0 |
| Intel® Turbo Boost Technology 2.0 frequency | 3,7 GHz |
| Intel® vPro™ Platform Eligibility | Yes |
| Bus bandwidth | 8 |
| Bus speed | 8 GT/s |
| Bus type units | GT/s |
| Last change | 63903513 |
| Launch date | Q1'17 |
| Maximum graphics card memory | 64 GB |
| Maximum memory | 64 GB |
| Maximum resolution & refresh rate (DisplayPort) | 4096x2304@60Hz |
| Maximum resolution & refresh rate (HDMI) | 4096x2160@24Hz |
| Maximum resolution & refresh rate (Integrated Flat Panel) | 4096x2304@60Hz |
| Maximum resolution & refresh rate (VGA) | N/A |
| Processor brand name | Intel Xeon |
| Processor ID | 0x591D |
| Product family | Intel Xeon Processors |
| Product type | Processor |
| Servicing status | Baseline Servicing |
| Status | Launched |
| Supported memory types | DDR3L-SDRAM, DDR4-SDRAM |
| Vendor information | Brand Name Intel Warranty 1 År |
| Brand Name Intel | Warranty 1 År |
| Brand Name | Intel |
| Warranty | 1 År |
| Weight & dimensions | Processor package size 37.5 x 37.5 mm |
| Processor package size | 37.5 x 37.5 mm |
| Hovedkategori | Server, Computer & Printer Parts |
| Underkategori | CPUs |
